Replacing the Printhead
8
With the nozzles facing down and the metal contacts
toward the back, insert the Printhead into the Car-
riage. Carefully push the printhead firmly into the Car-
riage, ensuring that the nozzles and metal contacts
do not touch the carriage.
9
Pull the Printhead Fixer Cover down toward the front
to lock the Printhead in place.
10
Push the Printhead Fixer Lever toward the back of
the printer until it clicks.
11
Close the Top Cover.
