iPF765
• Using rolls with a 3-inch paper core
Holder Stopper (Left Side)
Align the tips (a) of the 3-Inch Paper Core Attachment L with the
holes (b) of the Holder Stopper and insert it firmly.
3
With the edge of the roll paper facing forward as
shown, insert the Roll Holder from the right of the
roll. Insert it firmly until the roll touches the flange
(a) of the Roll Holder, leaving no gap.
Basic Guide
Attaching the Roll Holder to Rolls
Roll Holder (Right Side)
Align the tips (a) of 3-Inch Paper Core Attachment R with the
holes (b) of the Roll Holder and insert it firmly.
11
