• Vertical velocity: Vertical velocity in km/h. +ve velocity uphill, -ve velocity downhill.

• Long accel: Longitudinal acceleration in g, +ve for forward acceleration.

• Lat accel: Lateral acceleration in g, +ve for acceleration to the left.

• Solution type: Indicator for what the unit is currently using to derive position: 0 = No sats; 1 = Standalone

using GNSS only; 2 = SBAS.

You can find more information on the VBO file format here.

Setup

1. Performance Box Touch has an internal patch antenna, meaning that in many circumstances, where the unit has a

clear view of the sky without any interference, an additional antenna is not required.

However, if required, mount the external GPS antenna (RLACS284) in the centre of the roof of the vehicle, away

from roof bars and other antennas. For more information on antenna mounting positions

click

here.
