Sound Setup

You can set up items related to the sound quality.
Touch the upper central area [
screen.
The Sound Setup screen is displayed.
• The Sound Setup screen can also be displayed by touching
[ ] (HOME) while displaying the Home screen.
■
Sound Setup Menu screen
Current source information display.
Touch this to change to the Home screen.
X-OVER (page 34)
Battery Voltage display.
bass engine (page 34)
Volume level indicator
Time Correction (page 33)
Defeat (page 35)
Tone Adjust (Bass/Treble) (page 34), Sub
Woofer Level (page 35)
EQ Setting (page 31)
Media Xpander (page 31)
Fader/Balance/Rear Speaker/Subwoofer (page
33)

Setting the Media Xpander (MX)

[Media Xpander] is selected on the Sound Setup Menu
screen.
Media Xpander (MX) makes vocals or instruments sound
] of the Home
distinct regardless of the music source. The Radio (FM),
USB Flash drive and iPod, will be able to reproduce the
music clearly even in cars with a lot of road noise.
Setting item:
Setting contents:
1
2
• The Media Xpander setting screen is returned to the Sound
Setup Menu screen if no operation has been performed for
more than 3 seconds.
• MP3/WMA/AAC/FLAC/WAV/APE can have its own MX
setting.
• When the Defeat setting is [On], you cannot perform the set
up.
• Not available when "bass engine" is set.
• The MX setting can be performed only when a source is
currently selected.

Equalizer Settings

[EQ Setting] is selected on the Sound Setup Menu screen.
EQ Setting has 3 modes, "Advanced EQ", "Basic EQ" and
"Preset EQ".
• When the Defeat setting is [On], you cannot perform the
set up.
• Not available when "bass engine" is set.
Adjusting the Parametric Equalizer
Curve (Advanced EQ/Basic EQ)
You can modify the Equalizer settings to create a response
curve more appealing to your personal taste.
This unit has "Advanced EQ" which can set 4 types of
speakers, and "Basic EQ" which can set 2 types of speakers.
■
Media Xpander
OFF (Initial setting) / MX 1 / MX 2/ MX 3
Touch [Media Xpander].
The Media Xpander setting screen is displayed.
Touch [Media Xpander] to switch the level.
OFF MX 1 MX 2 MX 3
Advanced EQ
OFF
31
