Set Up Guide
1
Turn the vehicle's Ignition switch to ACC.
2
Turn ON the i509-WRA-JK by pressing any key.
4
To get into the settings the parking brake sequence needs to be done. Engage the parking brake, release
the parking brake, and engage the parking brake again.
5
Vehicle information- Set the desired gauge information. (HOME/VEHICLE INFO/SETUP).
6
If a rear camera is present, turn it ON in the system menu. (HOME/FUNCTION/CAMERA/REVERSE CAMERA).
Troubleshooting Guide
Symptom
1
iPhone not working with
HDMI.
2
Android phone is not working
with HDMI.
3
iDatalink website says serial
number is invalid.
4 No output from RCA's
Possible Cause
Not using Apple HDMI to Lightning
adapter.
Didn't plug USB power into a 2A
source.
Using incorrect HDMI adapter.
Miracast adapter isn't plugged into
a 2A source.
Miracast adapter has resolution
settings that are too high.
Incorrect serial number is being
used.
Serial number may not be in
iDatalink database.
Maestro module is flashed for
amplified system.
i509-WRA-JK 20220404v1
Remedy
Purchase the HDMI to Lightning adapter
directly from Apple. Not all 3rd party
adapters work the same.
Do not plug into the USB from the Alpine
head unit. A third party USB adapter will
need to be used that is 2A.
If the phone has the feature to use an HDMI
adapter it must be the one purchased from
the manufacturer of the phone, not a third
party adapter.
Do not plug into the USB from the Alpine
head unit. A third party USB adapter will
need to be used that is 2A.
Plug the adapter into another monitor (for
example a television in the home) and reduce
the resolution settings.
In the i509-WRA-JK settings confirm the
serial number. MENU/SETUP/GENERAL/
ABOUT.
Call ADS at 1-866-427-2999 and verify.
Re-flash module for non-amplified system.
Jeep Wrangler
