Connection Of DVR-C320R/C310R (Sold Separately)
Hardwiring Cable
R Cam
Lin Cable
F Cam
Lin Cable
Remocon In
Remocon Out
Yellow
Red
Black
Cut the terminals.
Solder and heat shrink
to AUX Power Connector.
Rear Camera
Rear Camera
Extension Cable
Not Used
Not Used
Not Used
Red - Acc 12V+
Yellow -12V+
Black - Ground
AUX Power
3-pin Black Connector
i509-WRA-JK
DVR-C320R/C310R
Rear Camera Cable
Dash Cam Data
Dash Cam Video In
i509 Source Unit
IN
OUT
DISPLAY
USB
EX KEY
MAIN
Power Harness
Jeep Wrangler
20220404v1
˜ 18/22
CAMERA
GPS
SXM
PREOUT
REMOTE
ANTENNA
