HARDWARE INSTALLATION
GUIDE
Enterprise Wi-Fi Access Point
System Release 6.4.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XV2-2T1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cambium Networks XV2-2T1

Summary of Contents for Cambium Networks XV2-2T1

  • Page 1 HARDWARE INSTALLATION GUIDE Enterprise Wi-Fi Access Point System Release 6.4.1...
  • Page 2 Cambium recommends reviewing the Cambium Networks website for the latest changes and updates to products. Cambium does not assume any liability arising out of the application or use of any product, software, or circuit described herein;...

  • Page 3: Table Of Contents

    Contents Contents Chapter 1: About This User Guide Overview of Cambium Networks products Intended audience Purpose Related documents New hardware platforms Existing hardware platforms Acess Point (AP) management options XMS-Cloud Swift mobile application cnMaestro Essentials and cnMaestro X cnMaestro On-Premises...
  • Page 4 Calculated distances and power compliance margins Chapter 2: Packaging and Installation of Access Point Unpacking the Access Point Package contents Mounting the device Mounting XV3-8 Mounting XV2-2 Mounting XV2-2T/XV2-2T1 Mounting XE3-4 Mounting e410/e600 Mounting e510 Mounting e430 Mounting e700 Cambium Networks...

  • Page 5: Chapter 1: About This User Guide

    Cambium’s equipment and ancillary devices. It is recommended that all personnel engaged in such activities must be trained properly. Cambium Networks disclaims all liability whatsoever, implied or expressed, for any risk of damage, loss or reduction in system performance arising directly or indirectly out of the failure of the customer, or anyone acting on the customer's behalf, to abide by the instructions, system parameters, or recommendations made in this document.

  • Page 6: Related Documents

    The System Release 6.4.1 includes support for the following new hardware platform: Table 2: New hardware platform Hardware Description Platform XV2-2T1 Outdoor Wi-Fi 6 Access point, 2x2 Sector antenna Dual band 802.11ax 2x2, BLE, 2.5GbE Existing hardware platforms Table 3 lists the existing hardware platforms.

  • Page 7: Acess Point (Ap) Management Options

    3. Connect AP to the internet. It appears in the XMS-Cloud console in a few minutes. Swift mobile application 1. Download the Cambium Networks Swift application from the Google Play Store or Apple App Store. Chapter 1: About This User Guide...

  • Page 8: Cnmaestro Essentials And Cnmaestro X

    2. Open Swift app and follow the onscreen instructions. cnMaestro Essentials and cnMaestro X 1. Go to cloud.cambiumnetworks.com and register as a new user or sign-in with the existing credentials. 2. Create a new cnMaestro account or select an existing account. 3.

  • Page 9: Safety And Regulatory Information

    Exercise extreme care when working at heights. Grounding and protective earth Cambium Networks Enterprise Access Point (AP) devices must be properly grounded to protect against lightning. It is the responsibility of the user to install the equipment in accordance with national regulations.

  • Page 10: Human Exposure To Radio Frequency Energy

    Important regulatory information The Enterprise Wi-Fi AP product is certified as an unlicensed device in frequency bands where it is not allowed to cause interference to licensed services (called primary users of the bands). Radar avoidance In countries where radar systems are the primary band users, the regulators have mandated special requirements to protect these systems from interference caused by unlicensed devices.

  • Page 11: Usa And Canada Specific Information

    levels related to human exposure to radio frequency electromagnetic fields (110 MHz – 40 GHz) – general public. ICNIRP (International Commission on Non-Ionizing Radiation Protection) guidelines for the general public. See the ICNIRP website at http://www.icnirp.de/ and Guidelines for Limiting Exposure to Time- Varying Electric, Magnetic, and Electromagnetic Fields.

  • Page 12: Specific Expertise And Training Required For Professional Installers

    IC statement This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.

  • Page 13: Avoidance Of Weather Radars

    XV3-8 (5Gbps) XV2-2, XE3-4, and XV2-2T (2.5Gbps) For 2.5Gbps, Cambium Networks recommends CAT6 cable or better to cover the 100m maximum cable length runs. For shorter runs under about 30m, CAT5E cable is recommended. For high radio-frequency electric fields environments, shielded CAT5E or CAT6 type cabling is recommended.

  • Page 14: Wall Mount Guidelines

    Figure 1: Grounding and lightning protection on pole or tower Wall mount guidelines If you need to install AP on the wall of a building, then in addition to the general protection requirements, follow the below requirements also: Ensure that the position of the equipment is lower than the top of the building or its lightning air terminal.

  • Page 15: Training

    The installer needs to have basic competence in radio and IP network installation. The specific requirements applicable to the Cambium Networks Enterprise Wi-Fi AP must be gained by reading this User Guide and by performing sample setups at base workshop before live installments.

  • Page 16: Calculation Of Power Density And Distance

    Table 5: Antenna details Antenna Gain (for 2.4 GHz Gain (for 5 GHz in Gain (for 6 GHz in in dBi) dBi) dBi) XV3-8 Omnidirectional XV2-2 Omnidirectional XV2-2T Omnidirectional XV2-2T1 Sector 11.8 13.6 XE3-4 Omnidirectional 4.85 e410 Omnidirectional 4.55 4.25 e510 Omnidirectional e430...

  • Page 17: Calculated Distances And Power Compliance Margins

    USA and Canada. These are conservative distances that include compliance margins. Cambium Networks Enterprise Wi-Fi AP adheres to all applicable EIRP limits for transmit power when operating in MIMO mode. Separation distances and compliance margins include compensation for both transmitters.
  • Page 18 Product Regulatory Domain Power density S (mW/cm²) Distance d (cm) XV2-2T1 0.466/0.461 (2.4G/5G) 0.328/0.324 (2.4G/5G) 0.193/1.97 (2.4G/5G W/m²) XE3-4 0.24/0.35/0.02196 (2.4G/5G/6G) 0.20/0.29 (2.4G/5G) 0.1247/4.548/0.253 (2.4G/5G/6G W/m²) 25 e410 0.2506/0.4998 0.54/0.975 (2.4GHz/5GHz) 0.1947/5.737 (2.4G/5G W/ m²) e510 0.28/0.65 0.22/0.186 0.19/7.35 (2.4G/5G W/ m²) e430 0.139/0.164...

  • Page 19: Chapter 2: Packaging And Installation Of Access Point

    Package contents Mounting the device Unpacking the Access Point After you purchase a Cambium Networks Enterprise Wi-Fi AP, unpack the AP and check the package contents. 1. Open the AP package, and then carefully remove the contents. 2. Verify that all items listed in Package contents below are included in the package. Check each item for damage.
  • Page 20 Table 7: Types of mounting the device Access Point Wall Mount Ceiling Mount T-bar Mount Pole Mount Gang Mount Table Mount XV3-8 ü ü ü XV2-2 ü ü ü XV2-2T ü ü XV2-2T1 ü ü XE3-4 ü ü ü e410 ü ü ü e510 ü...

  • Page 21: Mounting Xv3-8

    Mounting XV3-8 The XV3-8 units are mounted either by ceiling mount, wall mounting or T-bar mounting method. Ceiling Mount To mount the XV3-8 unit on the ceiling, perform the following steps: 1. Determine where XV3-8 needs to be mounted and remove the ceiling tile. 2.
  • Page 22 Wall Mounting you can mount XV3-8/XE5-8 unit to any wall by using two screws with corresponding wall anchors. The ceiling mount bracket can be used as a template to align the screws with the unit. T-bar Mounting The XV3-8/XE5-8 can be secured to a 38mm ceiling T-bar rail by using the ceiling mount bracket. The A marking on the bracket must be used for this width T-bar rail.
  • Page 23 24mm T-Bar The XV3-8/XE5-8 unit can be mounted to a 24mm width T-bar rail using the clips built into the underside of the unit. The B marking on the bracket must be used for this width T-bar rail. 14mm T-Bar The XV3-8/XE5-8 unit can be mounted to a 14mm width T-bar rail using the clips built into the underside of the unit.

  • Page 24: Mounting Xv2-2

    Mounting XV2-2 The XV2-2 units are mounted either by using the ceiling mount, wall mounting or T-bar mounting method. Ceiling mount 1. Determine where XV2-2 needs to be mounted and remove the ceiling tile. 2. Using the hole template, mark the hole locations. 3.
  • Page 25 6. Run the RJ45 cable (s) through the 15mm hole and remount the ceiling tile. 7. Attach the RJ45 cable (s) to XV2-2 unit . 8. Slide XV2-2 into the mounting bracket. Wall mounting You can mount XV2-2 unit to any wall by using two screws with corresponding wall anchors. The ceiling mount bracket can be used as a template to align the screws with the unit.
  • Page 26 38mm T-Bar 24mm T-Bar The XV2-2 unit can be mounted to a 24mm width T-bar rail using the clips built into the underside of the unit. The B marking on the bracket must be used for this width T-bar rail. 14mm T-Bar The XV2-2 unit can be mounted to a 14mm width T-bar rail using the clips built into the underside of the unit.
  • Page 27 Chapter 2: Packaging and Installation of Access Point...

  • Page 28: Mounting Xv2-2T/Xv2-2T1

    4. Use the four mounting slots given on the back of the radio to mount it on the wall. 5. Make sure that four screws are attached to the back side of the XV2-2T/XV2-2T1 unit. Do not tighten the screws, completely.
  • Page 29 6. Hang the XV2-2T unit to the wall mount bracket and tighten the four screws as shown in below figure. Chapter 2: Packaging and Installation of Access Point...
  • Page 30 Pole mount with level bracket To mount the XV2-2T/XV2-2T1 unit on the pole, perform the following steps: 1. Insert the hose mounting clamp though the pole mounting level bracket. 2. Fix the clamp to the pole by applying 9.0 Nm torque.
  • Page 31 Pole mount with tilt bracket (Only for XV2-2T1) To mount the XV2-2T1 unit on the pole, perform the following steps: 1. Assemble the pole mount holder to XV2-2T1 by using the four M5 screws, as shown below. Chapter 2: Packaging and Installation of Access Point...
  • Page 32 2. Install the pole mount bracket to the pole by using two hose clamps with the 9Nm torque. 3. Assemble XV2-2T1 (with pole mount holder) to pole mount bracket. Use M12 stud, washer, and M12 nut to secure it by applying 3Nm torque, as shown below.
  • Page 33 Chapter 2: Packaging and Installation of Access Point...

  • Page 34: Mounting Xe3-4

    Mounting XE3-4 The XE3-4 units are mounted by using one of the following mounting techniques: Ceiling mount, Wall mounting, or T-bar mounting. Ceiling mount To mount the XE3-4 unit by using the ceiling mount technique, perform the following steps: 1. Determine a place or location where you want to mount the XE3-4 unit. 2.
  • Page 35 5. Drill the RJ45 cable hole using a 15 mm (5/8”) diameter bit. 6. Hold the mounting plate on the top side of the ceiling tile and screw it on the mounting bracket. 7. Run the RJ45 cable (s) through the 15mm hole and remount the ceiling tile. 8.
  • Page 36 24mm T-Bar The XE3-4 unit can be mounted to a 24mm width T-bar rail using the clips built into the underside of the unit. The B marking on the bracket must be used for this width T-bar rail. Chapter 2: Packaging and Installation of Access Point...
  • Page 37 14mm T-Bar The XE3-4 unit can be mounted to a 14mm width T-bar rail using the clips built into the underside of the unit. The C marking on the bracket must be used for this width T-bar rail. Chapter 2: Packaging and Installation of Access Point...

  • Page 38: Mounting E410/E600

    Mounting e410/e600 The e410/e600 units are mounted by using one of the following mounting techniques: Ceiling mount, Wall mounting, or T-bar mounting. Ceiling mount To mount the e410/e600 unit by using the ceiling mount technique, perform the following steps: 1. Determine where the AP needs to be mounted and remove the ceiling tile. 2.
  • Page 39 7. Attach the RJ45 cable to the device. 8. Slide the device into the mounting bracket. Wall mounting You can mount e410/e600 to any wall by using two screws with corresponding wall anchors. The ceiling mount bracket can be used as a template to align the screws with the unit. Chapter 2: Packaging and Installation of Access Point...
  • Page 40 T-Bar mounting 38mm T-Bar: The e410/e600 can be secured to a 38mm ceiling T-bar rail by using the ceiling mount bracket. Chapter 2: Packaging and Installation of Access Point...
  • Page 41 24mm T-Bar The e410 can be mounted to a 24mm width T-bar rail using the clips built into the underside of the unit. 14mm T-Bar The e410 can be mounted to a 14mm width T-bar rail using the clips built into the underside of the unit. Chapter 2: Packaging and Installation of Access Point...

  • Page 42: Mounting E510

    Mounting e510 The e510 units are mounted by using one of the following mounting techniques: Pole mount Wall mounting Pole mount Insert hose clamps through pole mounting bracket and clamp to pole by applying 6.0Nm torque. Wall mounting Chapter 2: Packaging and Installation of Access Point...
  • Page 43 1. Drill 4 holes of Ø6mm (Ø0.25” Inch) on wall. 2. Press fit plastic anchor and assembly fastener. 3. Leave 5mm to 6mm gap between wall and fastener head. 4. Use the four mounting slots given on the back of the radio to mount to the wall. Chapter 2: Packaging and Installation of Access Point...

  • Page 44: Mounting E430

    Mounting e430 Single gang mounting 1. Remove single-gang box cover. 2. Place Cambium single-gang wall bracket on the gang box and secure with at least 2 screws. 3. Connect Ethernet cable to the upper RJ-45 port labelled Eth1/PoE at the rear side of e430 to provide connectivity.
  • Page 45 Dual gang mounting 1. Remove dual-gang box cover. 2. Place Cambium dual-gang wall bracket on the gang box and secure with at least two screws. Chapter 2: Packaging and Installation of Access Point...
  • Page 46 3. Slide the plastic cover over the exposed portion next to the mounted e430. 4. Connect Ethernet cable to the upper RJ-45 port labelled Eth1/PoE at the rear side of e430 to provide connectivity. Use the other RJ-45 port labelled Pass-thru for any additional cable that might need to pass through e430.
  • Page 47 Wall mounting 1. Choose location on the wall to mount the bracket using the four mounting screws and anchors (if needed). 2. Connect the short Ethernet jumper cable between the two RJ-45 connections on the rear side of e430. 3. Mount e430 into the Generic Wall bracket by aligning the hooks. Chapter 2: Packaging and Installation of Access Point...
  • Page 48 4. Secure e430 to the bracket using Torx (or standard) screw on the lower edge of e430. 5. Power e430 either with a 48Vdc/1A power adapter or using the PASS-THRU port at the bottom edge of the device using Ethernet power. Chapter 2: Packaging and Installation of Access Point...

  • Page 49: Mounting E700

    Mounting e700 The e700 units are mounted by using one of the following mounting techniques: Pole mount Wall mounting Pole mount 1. Assemble the radio holder to the pole mounting bracket and secure it with M8 nuts by applying 3.0 Nm torque. 2.
  • Page 50 4. Insert RJ45 to radio housing and the lock cable gland to radio housing with 1.5Nm to 2Nm torque. 5. Align Radio to required angle by tilting up and down. The maximum radio tilting angle is ± 40°, with an incremental of 10°. Chapter 2: Packaging and Installation of Access Point...
  • Page 51 Wall mounting 1. Drill 4 holes of Ø6mm (Ø0.25” Inch) on wall. 2. Press fit plastic anchor and assembly fastener. 3. Leave 5mm to 6mm gap between wall and fastener head. 4. Use the four mounting slots given on the back of the radio to mount to the wall. Chapter 2: Packaging and Installation of Access Point...

  • Page 52: Cambium Networks

    Devon, TQ13 7UP United Kingdom www.cambiumnetworks.com Cambium Networks and the stylized circular logo are trademarks of Cambium Networks, Ltd. All other trademarks are the property of their respective owners. Copyright © 2022 Cambium Networks, Ltd. All rights reserved. Cambium Networks...
