Page 18: Chapter 1: Product Description
Chapter 1: Product description This chapter provides a high level description of products in the PTP 550 series. It describes in general terms the function of the product, the main product variants and the main hardware components. The following topics are described in this chapter: •...
Page 19: Overview Of The Ptp 550 Series
Purpose Cambium PTP 550 products are designed for Ethernet bridging over point-to-point links in the unlicensed 5 GHz frequency band. Users must ensure that the PTP 550 Series complies with local operating regulations. The PTP 550 acts as a transparent bridge between two segments of the operator’s network. In this sense, it can be treated as a virtual wired connection between two points.
Page 20: Frequency Bands
Chapter 1: Product description Overview of the PTP 550 Series A summary of the main PTP 550 characteristics is listed under Table Table 1 Main characteristics of the PTP 550 Series Characteristic Value Topology Wireless link condition LOS, near LOS...
Page 21: Typical Bridge Deployment
Chapter 1: Product description Overview of the PTP 550 Series Typical bridge deployment The PTP 550 is an “all outdoor” solution consisting of a wireless bridge between two sites. Each site installation consists of a PTP 550 Integrated or PTP 550 Connectorized outdoor unit...
Page 22: Hardware Overview
Chapter 1: Product description Overview of the PTP 550 Series Figure 1 PTP 550 typical bridge deployment Hardware overview The main hardware components of the PTP 550 are as follows: • Outdoor unit (ODU): The ODU is a self-contained transceiver unit that houses both radio and networking electronics.
Page 23 Chapter 1: Product description Overview of the PTP 550 Series • The ODU is supplied in the following regional variants: FCC, intended for deployment in the USA IC, intended for deployment in Canada EU, intended for deployment in countries of the European Union or other countries...
Page 24: Wireless Operation
Chapter 1: Product description Wireless operation Wireless operation This section describes how the PTP 550 wireless link is operated, including modulation modes, power control and security. Channel Bonding PTP 550 features three radio interfaces – two radios are used for data transfer and one radio is used for a real time spectrum analyzer and Dynamic Channel Selection (supported in a future release).
Page 25: Time Division Duplexing
Chapter 1: Product description Wireless operation Time division duplexing TDD cycle PTP 550 links operate using Time Division Duplexing (TDD). They use a TDD cycle in which the ODUs alternately transmit and receive TDD bursts. The TDD cycle is illustrated in Figure 2.
Page 26 Chapter 1: Product description Wireless operation Figure 2 TDD cycle – single channel Page 1-9...
Page 27: Link Scheduler
Chapter 1: Product description Wireless operation Link Scheduler The PTP 550 series provides three configuration options for apportioning the available capacity between the two link directions. • 75/25 – The capacity in the direction Master to Slave comprises 75% of available TDD frame, and the capacity in the direction of Slave to Master comprises 25% of available TDD frame.
Page 28: Adaptive Modulation
Chapter 1: Product description Wireless operation Adaptive modulation The PTP 550 can transport data over the wireless link using a number of different modulation modes ranging from 256-QAM to QPSK (selected independently between the two channels of operation). For a given channel bandwidth and TDD frame structure, each modulation mode transports data at a fixed rate.
Page 29: Encryption
Chapter 1: Product description Wireless operation Note The system automatically chooses between dual and single payload to try to increase the capacity of a link. Further reading For information about… Refer to… Single and dual payload modulation modes System threshold on page 3-36 Encryption...
Page 30: Ptp Networks
Chapter 1: Product description Wireless operation For sub-band 5.8 GHz, the maximum configurable transmit power of each radio is reduced by 6 dBm • If the configured channel on either radio spans two neighboring sub-bands, then the maximum configurable transmit power of each radio complies to the most conservative sub-band.
Page 31: Ethernet Bridging
Data network Transparent Ethernet service The PTP 550 Series provides an Ethernet service between one of the Ethernet ports at a local ODU and one of the Ethernet ports at an associated remote ODU. The service is transparent to untagged frames, standard VLAN frames, priority-tagged frames, provider bridged frames, and provider backbone bridged frames.
Page 32 Chapter 1: Product description Ethernet bridging Frames are transmitted at the Wireless port over a proprietary point-to-point circuit-mode link layer between ends of the PTP 550 link. Ethernet frames received at the Ethernet ports, or generated internally within the management agent, are encapsulated within a lightweight MAC layer for transmission over the wireless link.
Page 33: System Management
Chapter 1: Product description System management System management This section introduces the PTP 550 management system, including the web interface, installation, configuration, alerts and upgrades. Management agent PTP 550 equipment is managed through an embedded management agent. Management workstations, network management systems or PCs can be connected to this agent using an in- band network management mode.
Page 34: Network Management
Chapter 1: Product description System management Network management IPv4 and IPv6 interfaces The PTP 550 ODU contains an embedded management agent with IPv4 and IPv6 interfaces. Network management communication is exclusively based on IP and associated higher layer transport and application protocols. The default IPv4 address of the management agent is 169.254.1.1.
Page 35: Snmp
The management agent supports fault and performance management by means of an SNMP interface. The management agent is compatible with SNMP v2c using one Management Information Base (MIB) file which is available for download from the Cambium Networks Support website http: Further reading For information about…...
Page 36: Network Time Protocol (Ntp)
Chapter 1: Product description System management Network Time Protocol (NTP) The clock supplies accurate date and time information to the system. It can be set to run with or without a connection to a network time server (NTP). It can be configured to display local time by setting the time zone on the System web page.
Page 37: System Logging (Syslog)
SNMP interface, or cnMaestro management software. PTP 550 software images are digitally signed, and the ODU will accept only images that contain a valid Cambium Networks digital signature. The ODU always requires a reboot to complete a software upgrade.
Page 38 Chapter 1: Product description System management Further reading For information about… Refer to… How to upgrade the software using the web Tools > Software Upgrade page on page 6-49. interface Page 1-21...
Page 39: Chapter 2: System Hardware
Chapter 2: System hardware This chapter describes the hardware components of a PTP 550 link. The following topics are described in this chapter: • Outdoor unit (ODU) on page • Power supply units (PSU) on page • Antennas and antenna cabling on page 2-12 •...
Page 40: Outdoor Unit (Odu)
Chapter 2: System hardware Outdoor unit (ODU) Outdoor unit (ODU) ODU description One ODU is required for each link end. The ODU is a self- contained transceiver unit that houses both radio and networking electronics. Hardware platform variants PTP 550 ODUs are available in two different hardware platform variants: •...
Page 41 Chapter 2: System hardware Outdoor unit (ODU) Figure 3 PTP 550 Integrated ODU (front and rear views) Integrated ODU kit part numbers Order PTP 550 Integrated ODU kits from Cambium Networks (Table Each of the parts listed in Table 3 includes the following items: •...
Page 42: Ptp 550 Connectorized Odu
Chapter 2: System hardware Outdoor unit (ODU) PTP 550 Connectorized ODU The PTP 550 Connectorized ODU is intended to work with separately mounted external antennas (Figure 4) in long-range difficult links and traditional backhaul requirements where high capacity and high link budget are required. External antennas generally have higher gains than the integrated antennas, allowing the PTP 550 to cope with more difficult radio conditions.
Page 43: Odu Accessories
PTP 550 Connectorized 5 GHz (ROW) with EU Line Cord C050055H005A PTP 550 Connectorized 5 GHz (ROW) with No Line Cord C050055H006A ODU accessories Spare ODU port blanking plugs are available from Cambium Networks (Table Table 5 ODU accessory part numbers Cambium description Cambium part number...
Page 44: Odu Interfaces
Chapter 2: System hardware Outdoor unit (ODU) The low profile bracket provides elevation adjustment of +10° to –5° or +5° to –10°. If separate ODU mounting brackets are required, order them from Cambium Networks. Figure 5 ODU low profile bracket ODU interfaces...
Page 45 Chapter 2: System hardware Outdoor unit (ODU) Port name Connector Interface Description Optical or Copper Management and/or data. Gigabit Ethernet The front of the connectorized ODU (Figure 7) provides N type female connectors for RF cable interfaces to antennas with horizontal (H) and vertical (V) polarization. Figure 7 Connectorized ODU antenna interfaces Page 2-7...
Page 46: Odu Specifications
Chapter 2: System hardware Outdoor unit (ODU) ODU specifications The PTP 550 ODU conforms to the specifications listed in Table Table 8 ODU specifications Category Specification Dimensions 23 dBi integrated: 305 mm (12.0 in) x 305 mm (12.0 in) x 68 mm (2.2 in) Connectorized: 278 mm (11.0 in) x 185 mm (7 in) x 88 mm (3.5 in) Weight 23 dBi integrated: 2.2 Kg (4.85 lbs) including bracket...
Page 47: Power Supply Units (Psu)
Chapter 2: System hardware Power supply units (PSU) Power supply units (PSU) PSU description The PSU is an indoor unit that is connected to the ODU and network terminating equipment using Cat5e cable with RJ45 connectors. It is also plugged into an AC power supply so that it can inject Power over Ethernet (POE) into the ODU.
Page 48: Psu Part Numbers
Chapter 2: System hardware Power supply units (PSU) PSU part numbers Order PSUs and (for AC power) line cords from Cambium Networks (Table Table 9 Power supply component part numbers Cambium description Cambium part number PTP 550 AC Power Injector...
Page 49 Chapter 2: System hardware Power supply units (PSU) Weight 0.240 Kg (0.5 lbs) Temperature 0°C to +40°C Humidity 90% non-condensing Waterproofing Not waterproof Altitude Sea level to 5000 meters (16000 ft) AC Input Min 90 V AC, 57 – 63 Hz, max 264 V AC, 47 – 53 Hz. DC output voltage to the ODU 55V +/- 5% AC connector...
Page 50: Antennas And Antenna Cabling
Lightning arrestors: When the connectorized ODU is mounted indoors, lightning arrestors are required for protecting the antenna RF cables at building entry. One arrestor is required per antenna cable. One example of a compatible lightning arrestor is the Polyphaser LSXL- ME or LSXL (not supplied by Cambium Networks). Page 2-12...
Page 51: Ethernet Cabling
Chapter 2: System hardware Ethernet cabling Ethernet cabling Ethernet standards and cable lengths All configurations require a copper Ethernet connection from the ODU (PSU port) to the PSU. Advanced configurations may also require one the following: • An optical or copper Ethernet connection from the ODU (SFP port) to network terminating equipment or a linked ODU.
Page 52: Outdoor Copper Cat5E Ethernet Cable
(Figure 11). Caution Always use Cat5e cable that is gel-filled and shielded with copper-plated steel. Alternative types of drop cable are not supported by Cambium Networks. Order Superior Essex type BBDGe cable from Cambium Networks (Table 21). Other lengths of this cable are available from Superior Essex.
Page 53: Cable Grounding Kit
One grounding kit (Figure 12) is required for each grounding point on the PSU and copper SFP drop cables. Order cable grounding kits from Cambium Networks. Caution To provide adequate protection, all grounding cables must be a minimum size of 10...
Page 54: Rj45 Connectors And Spare Glands
The RJ45 connectors and crimp tool listed in Table 25 work with Superior Essex type BBDGe cable (as supplied by Cambium Networks). They may not work with other types of cable. The ODU is supplied with one environmental sealing gland for the drop cable. However, this is not suitable when surge protection is required: EMC glands must be used instead.
Page 55: Drop Cable Tester
(MDI-X networks) or straight-through cables (MDI Networks). SFP module kits SFP module kits allow connection of a PTP 550 Series ODU to a network over a Gigabit Ethernet interface in one of the following full-duplex modes: •...
Page 56 Chapter 2: System hardware Ethernet cabling Table 19 Single Mode Optical SFP Interface per ODU (part number C000065L008) Core/ Mode Bandwidth at Maximum Insertion loss cladding 1310 nm length of optical (dB) (microns) (MHz/km) interface 62.5/125 Multi 550 m (1800 ft) 1.67 50/125 Multi...
Page 57: Optical Cable And Connectors
Chapter 2: System hardware Ethernet cabling Figure 15 Long cable gland Note PTP 550 does not support the Synchronous Ethernet or 1588 Transparent Clock features using copper SFP transceivers. Optical cable and connectors Order an optical cable with LC connectors from a specialist fabricator, quoting the specification shown in Figure 17.
Page 58: Chapter 3: System Planning
Chapter 3: System planning Ethernet cabling Chapter 3: System planning This chapter provides information to help the user to plan a PTP 550 link. The following topics are described in this chapter: • Site planning on page 3-21 describes factors to be considered when planning the proposed link end sites, including grounding, lightning protection and equipment location.
Page 59: Site Planning
Chapter 3: System planning Site planning Site planning This section describes factors to be considered when planning the proposed link end sites, including grounding, lightning protection and equipment location for the ODU and PSU. Grounding and lightning protection Warning Electro-magnetic discharge (lightning) damage is not covered under warranty. The recommendations in this guide, when followed correctly, give the user the best protection from the harmful effects of EMD.
Page 60: Site Grounding System
Chapter 3: System planning Site planning Figure 17 Rolling sphere method to determine the lightning protection zones Zone A: In this zone a direct lightning strike is possible. Do not mount equipment in this zone. Zone B: In this zone, direct EMD (lightning) effects are still possible, but mounting in this zone significantly reduces the possibility of a direct strike.
Page 61: Odu And External Antenna Location
Chapter 3: System planning Site planning ODU and external antenna location Find a location for the ODU (and external antenna for connectorized units) that meets the following requirements: • The equipment is high enough to achieve the best radio path. •...
Page 62: Psu Ac Power Supply
Chapter 3: System planning Site planning Table 22 ODU wind loading (pounds force ) Type of ODU Max surface Wind speed (miles per hour) area (square feet) Integrated (23 dBi) 1.40 69 lb 85 lb 103 lb 123 lb 145 lb Connectorized 0.55 38 lb...
Page 63 Chapter 3: System planning Site planning • The drop cable shield must be bonded to the building grounding system at its top entry point (usually on the roof). • The drop cable shield must be bonded to the building grounding system at the entry point to the equipment room.
Page 64: Radio Spectrum Planning
Chapter 3: System planning Radio spectrum planning Radio spectrum planning This section describes how to plan PTP 550 links to conform to the regulatory restrictions that apply in the country of operation. Caution It is the responsibility of the user to ensure that the PTP product is operated in accordance with local regulatory limits.
Page 65: Regulatory Limits
(integrated) Regulatory limits Many countries impose EIRP limits (Allowed EIRP) on products operating in the bands used by the PTP 550 Series. For example, in the 5.4 GHz and 5.8 GHz bands, these limits are calculated as follows: • In the 5.4 GHz band (5470 MHz to 5725 MHz), the EIRP must not exceed the lesser of 30 dBm or (17 + 10 x Log Channel width in MHz) dBm.
Page 66: Channel Bandwidth
Chapter 3: System planning Radio spectrum planning The number and identity of channels barred by the license key and regulatory band is dependent on the channel bandwidth and channel raster selected. Channel bandwidth Select the required channel bandwidth for the link. The selection depends upon the regulatory band selected.
Page 67: Link Planning
The PTP 550 Series will operate at ranges from 100 m (330 ft) to 200 km (122 miles). Operation of the system will depend on obstacles in the path between the units. Operation at 40 km (25 miles) or above will require a near line-of-sight path.
Page 68: Adaptive Modulation
Chapter 3: System planning Link planning Seasonal Fading (dB) seasonal Equipment Capability (dB) capability Adaptive modulation Adaptive modulation ensures that the highest throughput that can be achieved instantaneously will be obtained, taking account of propagation and interference. When the link has been installed, web pages provide information about the link loss currently measured by the equipment, both instantaneously and averaged.
Page 69: Planning For Connectorized Units
Chapter 3: System planning Planning for connectorized units Planning for connectorized units This section describes factors to be taken into account when planning to use connectorized ODUs with external antennas in PTP 550 links. When to install connectorized units The majority of radio links can be successfully deployed with the integrated ODU. However, the integrated units may not be sufficient in some areas, for example: •...
Page 70 Chapter 3: System planning Planning for connectorized units Note Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (EIRP) is not more than that necessary for successful communication.
Page 71: Data Network Planning
Chapter 3: System planning Data network planning Data network planning This section describes factors to be considered when planning PTP 550 data networks. Ethernet interfaces The PTP 550 Ethernet ports conform to the specifications listed in Table Table 25 PTP 550 Ethernet bridging specifications Ethernet Bridging Specification Protocol...
Page 72: Network Management Planning
Chapter 3: System planning Network management planning Network management planning This section describes how to plan for PTP 550 links to be managed remotely using SNMP. Enabling SNMP Enable the SNMP interface for use by configuring the following attributes in the SNMP Configuration page: •...
Page 73: Security Planning
Chapter 3: System planning Security planning Security planning This section describes how to plan for PTP 550 links to operate in secure mode. Planning for NTP operation Note PTP 550 does not have a battery-powered clock, so the set time is lost each time the ODU is powered down.
Page 74: System Threshold
Chapter 3: System planning System threshold System threshold Use the following table to reference system threshold (dBm) for the PTP 550 system: Table 26 5 GHz: system threshold (dBm) Modulation mode 20 MHz 40 MHz 80 MHz Lowest MCS Highest MCS Page 3-36...
