Enhancements
Release L.11.08 Enhancements
Figure 5 shows an example of an MSTP instance configured with the VLAN range option. All the
VLANs are included in the instance whether they exist or not. Figure 6 shows an example of an MSTP
instance configured on a ProCurve switch other than the Series 3500/5400/6200. Only VLANs 1, 5, and
7 are included in the instance.
ProCurve(config)# show spanning-tree mst-config
MST Configuration Identifier Information
MST Configuration Name: MSTP1
MST Configuration Revision: 1
MST Configuration Digest: 0x51B7EBA6BEED8702D2BA4497D4367517
IST Mapped VLANs :
Instance ID Mapped VLANs
-------- ---------------
1 1-10
Figure 5. An Example of Mapping VLANs with the Range Option where all VLANs are Included
The Configuration Digest value in Figure 6 is not the same as in Figure 5, indicating that these switches
do not operate in the same instance.
The Common Spanning Tree (CST) will still have the correct root associations.
ProCurve(config)# show spanning-tree mst-config
MST Configuration Identifier Information
MST Configuration Name: MSTP1
MST Configuration Revision: 1
MST Configuration Digest: 0x89D3ADV471668D6D832F6EC4AA9CF4AA
IST Mapped VLANs :
Instance ID Mapped VLANs
-------- ---------------
1 1, 5, 7
Figure 6. Example of Mapping VLANs on Switches other than ProCurve Series 3500/5400/6200
Operating Notes
■ Configuring MSTP on the switch automatically configures the Internal Spanning Tree (IST)
instance and places all statically and dynamically configured VLANs on the switch into the
IST instance. The spanning-tree instance vlan command creates a new MST instance and
moves the VLANs you specify from the IST to the MSTI.
