HP Procurve Switch
10/100-TX XL Module
(J4820A)
HP Procurve Switch
100/1000-T XL Module
(J4821A)
HP Procurve Switch
mini-GBIC XL Module
(J4878A)
* Supported mini-GBICs: The following HP Procurve mini-GBICs are supported by the mini-GBIC XL Module (as of this
printing): • Gigabit-SX LC mini-GBIC (J4858A) • Gigabit-LX LC mini-GBIC (J4859A) • Gigabit-LH LC mini-GBIC (J4860A)
HP Procurve Switch
100-FX MTRJ
†
XL Module (J4852A)
†
This module requires switch software version E.07.01 or later to be installed in the switch.
HP Procurve Switch XL Modules
For the HP Procurve Series 5300XL Switches
Descriptions. The HP Procurve Switch XL Modules are components that you
can add to an HP Procurve XL switch to provide a variety of network connec­
tivity options. The following modules are available as of this printing:
Module
Contact your HP-authorized networking products reseller or your HP repre­
sentative for information on availability of other modules and mini-GBICs. You
can also visit the HP networking products Web site at http://www.hp.com/go/
hpprocurve to get more information.
HP Procurve Switch XL Modules

Descriptions

Description
24 twisted-pair ports with RJ-45
connectors for 10 Mbps or 100
Mbps operation over 100-ohm
unshielded (UTP) or shielded (STP)
twisted-pair cable -- all ports have
the HP Auto-MDIX feature.
4 twisted-pair ports with RJ-45
connectors for 1000 Mbps
(Gigabit) or 100 Mbps operation
over Category 5 or better 100-ohm
UTP or STP cable (category 5E
recommended for Gigabit) -- all
ports have the IEEE 802.3ab Auto
MDI/MDI-X feature.
4 slots for installing any of the
supported HP Procurve mini-
GBICs*.
12 100-FX ports with MT-RJ
connectors for 100 Mbps
networking over multimode
fiber-optic cable.
