HP Procurve Switch XL Modules
Troubleshooting
Tip
Number Problem
➍
The network port for
which the Link LED is
flashing has
experienced a self test
or initialization failure.
➎
The network port for
which the Link LED is
flashing has been
disabled because port
security has been
configured on the
switch and a security
violation has been
detected on the port.
18
During the module self test (described in item 1 above), each network port is also
tested. If the port self test fails, the individual port is not usable, but the rest of
the ports on the module, which have passed their self test, will continue to
operate normally.
If the error has occurred on a mini-GBIC that you have installed in the mini-GBIC
XL Module, make sure that it is one of the supported mini-GBICs. The HP
Procurve mini-GBICs that are supported, as of the printing of this manual, are
listed on page 1. Use only the supported HP Procurve mini-GBICs. If it is a
supported mini-GBIC, it may have failed. Try removing and reinstalling the mini-
GBIC and it will be tested again. If the fault indication reoccurs, the mini-GBIC is
faulty and must be replaced.
If the error has occurred a port that is a known valid mini-GBIC or on a twisted­
pair port or 100-FX port on one of the other modules, try removing and reinstalling
the module. If the port fault indication reoccurs, and you need to be able to use
the port, you will have to replace the module. In the mean time, all the other ports
on the module will operate normally.
For the Port Security feature, you can configure the switch so that whenever a
security violation is detected on a port, the switch will disable the port. When a
port is disabled by this feature, the port Link LED will be continuously flashed at
the fast rate of 0.8 seconds per cycle. The flashing continues until you clear the
security violation through the switch console. In the console, you can view the
identity of the connected device that committed the security violation.
Once the security violation is cleared, you must re-enable the port through the
console.
For more information on the Port Security feature, see the Management and
Configuration Guide that is on the documentation CD-ROM that came with your
switch.
Solution
