Hub Reference

Front and Back Panel Descriptions

Front Panel
The 24-port hub is shown; the 12-port and 48-port hubs are essentially the same.
hub status LEDs
and reset button
Optional AUI port module
ThinLAN
installed in AUI/Xcvr slot
network
port
chain ports RS-232 console port
(for distributed management)
Back Panel
power connector
3-2
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
twisted-pair port LEDs
twisted-pair ports
redundant power
slot for HP Ethernet SNMP Module
connector
cable management
guide
cover plate over
