HP ProCurve J4852A Install Manual

Hp procurve j4852a: install guide.
Hide thumbs

Advertisement

installation guide
hp procurve switch
xl modules
www.hp.com/go/hpprocurve

Advertisement

   Related Manuals for HP ProCurve J4852A

   Summary of Contents for HP ProCurve J4852A

  • Page 1

    www.hp.com/go/hpprocurve...

  • Page 3

    HP Procurve Switch XL Modules Installation Guide...

  • Page 4

    Hewlett-Packard. Warranty See the Customer Support/Warranty booklet included with the product. A copy of the specific warranty terms applicable to your Hewlett-Packard product and replacement parts can be obtained from your HP sales and service office or HP-authorized reseller.

  • Page 5: Table Of Contents

    Reasons for Resetting the Switch ......15 Methods of Resetting the Switch ....... 15 Troubleshooting .

  • Page 6

    Mode Conditioning Patch Cord for Gigabit-LX ....24 Installing the Patch Cord ........25 Recommended Patch Cords .

  • Page 7: Descriptions

    XL Module (J4878A) * Supported mini-GBICs: The following HP Procurve mini-GBICs are supported by the mini-GBIC XL Module (as of this printing): • Gigabit-SX LC mini-GBIC (J4858A) • Gigabit-LX LC mini-GBIC (J4859A) • Gigabit-LH LC mini-GBIC (J4860A) HP Procurve Switch 100-FX MTRJ †...

  • Page 8: Features

    Link and Mode LEDs (one pair per port) network ports The HP Procurve Switch XL Modules have the following features: auto-enabled ports—the ports are all configured to be ready for network ■ operation as soon as a viable network cable is connected ■...

  • Page 9

    10/100-TX XL Module have the HP Auto-MDIX feature, ■ and the ports on the 100/1000-T XL Module have the IEEE 802.3ab Auto MDI/MDI-X feature. These features operate the same way and allow you to use either “straight-through” or “crossover” twisted-pair cables for all the twisted-pair network connections.

  • Page 10: Installing The Modules, Overview

    Installing the Modules Installing the Modules Overview You can install any of the modules into any of the HP Procurve XL Switches that have a compatible module slot. As of this printing, those are the HP Procurve Series 5300XL Switches: ■...

  • Page 11: Installing The Module In An Unused Slot, Installation Precautions, Installation Procedures

    • When installing the module, equalize any static charge difference between your body and the switch by wearing a grounding wrist strap and attaching it to the switch’s metal body, or by frequently touching the switch’s metal body. ■...

  • Page 12

    HP Procurve Switch XL Modules Installing the Modules Insert module into the guides and slide it in until it is fully inserted. The module is fully inserted when the module bulkhead is contacting, or very close to contacting the face of the switch.

  • Page 13: Installing Or Removing The Mini-gbics

    Installing or Removing the mini-GBICs You can install or remove the mini-GBIC from the mini-GBIC XL Module without having to power off the switch. Use only HP Procurve mini-GBICs. C a u t i o n The HP Procurve mini-GBICs are Class 1 laser devices. Avoid direct eye exposure to the beam coming from the transmit port.

  • Page 14: Verifying The Module Is Installed Correctly

    Verifying the Module is Installed Correctly Observe the Module Status LED for the slot in which the module is being installed, and the Self Test and Fault LEDs on the switch to verify that the module is installed properly. Fault LED...

  • Page 15: Connecting The Network Cables

    Notes: • The RJ-45 ports on this module have the HP Auto-MDIX feature. In the module’s default configuration, Auto, either a straight-through or crossover cable can be used to connect the module to any other 100Base-TX or 10Base-T device. See the Note on page 11.

  • Page 16

    HP Procurve Switch XL Modules Installing the Modules Module mini-GBIC XL Module fiber-optic cable with LC connector Notes: Gigabit-LX – If multimode cable is used, a mode conditioning patch cord may be needed — see “Mode Conditioning Patch Cord” on page 24 for more information.

  • Page 17

    “crossover” twisted-pair cable for all network connections to these modules. On the 10/100-TX XL Module, this feature is identified as HP Auto-MDIX; on the 100/1000-T XL Module, it is identified as Auto MDI/MDI-X and it is part of the IEEE 802.3ab standard. Both features operate the same.

  • Page 18: Verifying The Network Connections Are Working

    Check the port LEDs for the newly-installed module to ensure that the port(s) connected in the preceding step are operating correctly. Each port on the switch modules has Link and Mode LEDs near it as shown in the next illustration.

  • Page 19: Customizing The Port Configuration

    Customizing the Port Configuration If the slot in which you installed the module was empty the last time the switch was either rebooted or reset (or the power to the switch was cycled), then the module will use preconfigured default parameter values that will work for most networks.

  • Page 20: Replacing Or Removing A Module

    Grab the screws and pull the module out from the slot. It may help to brace your hands against the face of the switch and “lever” the module out from the switch slot.

  • Page 21: Resetting The Switch, Reasons For Resetting The Switch, Methods Of Resetting The Switch

    Resetting the Switch Reasons for Resetting the Switch Generally, you only need to reset the switch when it needs to recognize a change in its hardware or software (console) configuration. Some circumstances in which you will need to reset the switch are: Installing a module in a slot that was previously occupied by a different ■...

  • Page 22: Troubleshooting, Switch And Module Led Error Indicators, Diagnostic Tips

    One of the primary tools for troubleshooting the switch modules are the LEDs on the front of the switch and on the modules. Refer to “LED Behavior” on page 8 for a description of the normal LED behavior. Also, refer to the switch Installation and Getting Started Guide for more detailed troubleshooting information for the switch.

  • Page 23

    Procurve Switch GL module and should not be used in your XL switch. Make sure that you have installed an XL module in the slot. HP Procurve GL modules will fit in the slot, but they are not compatible with your Procurve XL switch.

  • Page 24

    Procurve mini-GBICs that are supported, as of the printing of this manual, are listed on page 1. Use only the supported HP Procurve mini-GBICs. If it is a supported mini-GBIC, it may have failed. Try removing and reinstalling the mini- GBIC and it will be tested again.

  • Page 25

    You can use the console interface, or, if you have configured an IP address on the switch, use the web browser interface, or HP TopTools for Hubs & Switches network management software to determine the state of the port and re-enable the port if necessary.

  • Page 26: Customer Support Services, Specifications, Environmental, Lasers

    See the Customer Support/Warranty booklet that came with your switch for information on how to use these services to get technical support. The HP networking products World Wide Web site, http://www.hp.com/go/procurve also provides up-to-date support informa­...

  • Page 27: Connectors, Twisted-pair, Fiber-optic

    Gigabit-LX described on page 23. ■ Gigabit-LH LC – On the Gigabit-LH mini-GBIC. Transmits at 1300 nm wavelength, and accepts the low metal content, single-mode fiber-optic cables for Gigabit-LH described on page 23. HP Procurve Switch XL Modules Specifications...

  • Page 28: Cables, Twisted-pair Cables

    ELFEXT, and Return Loss. When testing your cabling, be sure to include the patch cables that connect the switch and other end devices to the patch panels on your site. The patch cables are frequently overlooked when testing cable and they must also comply with the cabling standards.

  • Page 29: Fiber-optic Cables

    This is equivalent to 20Km of the fiber-optic cable. For distances less than 20Km, you must add attenuators to bring the total attenuation to at least 5dB. Most cable vendors carry attenuators. HP Procurve Switch XL Modules Connector Maximum Length...

  • Page 30: Mode Conditioning Patch Cord For Gigabit-lx

    If you experience a high number of transmission errors on the Gigabit-LX ports, usually CRC or FCS errors, you may need to install one of these patch cords between the Gigabit-LX port in your switch and your multimode fiber­ optic network cabling, and between the Gigabit-LX transmission device and the network cabling at the other end of the multimode fiber-optic cable run.

  • Page 31: Installing The Patch Cord, Recommended Patch Cords

    Recommended Patch Cords Hewlett-Packard maintains a list of recommended Mode Conditioning Patch Cords that have been tested and verified to operate correctly with the HP Procurve Gigabit-LX Transceiver and HP Procurve Gigabit-LX LC mini-GBIC.

  • Page 32: Emc Regulatory Statements

    HP Procurve Switch XL Modules EMC Regulatory Statements EMC Regulatory Statements U.S.A. FCC Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against interference when the equipment is operated in a commercial environment.

  • Page 33: European Community Declaration Of Conformity

    EMC Regulatory Statements Korea Taiwan European Community Declaration of Conformity This product is designed for operation with the HP Procurve switches that have XL module slots. Please see the Declarations of Conformity included in the Installation Guides for those products.

  • Page 36

    Technical information in this document is subject to change without notice. � Copyright Hewlett-Packard Company, 2001, 2002. All rights reserved. Reproduction, adaptation, or translation without prior written permission is prohibited except as allowed under the copyright laws. Product of Singapore November 2002 Manual Part Number 5990-3069...
