- Page 1 SWH-2109FX SWH-2109W2X 7 PORT 10/100BASE-TX ETHERNET SWITCH WITH 2 PORT 100BASE-FX UPLINK FIBER (FIBER REDUNDANCY OPTION) User's Guide Ver: 1.1 第 1 頁，共 12 頁 SWH-2109F V1.1...
- Page 2 Trademarks CTS is a registered trademark of Connection Technology Systems Inc. Contents subject to revise without prior notice. All other trademarks remain the property of their owners. Copyright Statement Copyright © Connection Technology Systems Inc. This publication may not be reproduced as a whole or in part, in any way whatsoever unless prior consent has been obtained from Connection Technology Systems Inc.
- Page 3 Table of Contents 1. Unpacking Information 2. Introduction to 9 Port NWay Switching Hub General Description Key Features The Front Panel 2.3.1 System LEDs 2.3.1.1 Power LED 2.3.2 Port LEDs 2.3.2.1 100M LED 2.3.2.2 Link/Act LED 2.3.2.3 FDX/COL LED 2.3.3 Fiber Port LED 2.3.3.1 TP/Fiber LED...
- Page 4 Thank you for purchasing the 9-port SWH-2109F NWay switching hub. Before you start, please check all the contents of this package. The product package should include the following: 1. One 9-port NWay switching hub 2. One external power supply 3. Rubber foot 4.
- Page 5 2. Introduction to 9 Port NWay Switching Hub 2.1 General Description This device is a powerful, high-performance Ethernet / Fast Ethernet Switch with two fiber uplink ports. Twisted pair ports are capable of 10 or 100Mbps auto-negotiation operation (N-Way). 100Mbps according to the 100Base-FX standard are supported on the fiber interface.
- Page 6 standards Supports N-Way protocol for 10Base-T and/or 100Base-TX connections Full/ Half duplex mode operation Small size Store-and-forward switching mechanism Automatic filtering of fragmented and CRC error packets Extensive LED indicators for network diagnostics External power adapter State Monitor - Model/Media/Link/Speed/Duplex/Activity Enhanced Port Monitor –...
- Page 7 The auto-negotiation feature of the switching hub allows port 1 to port 8 running at one of the following four operation modes: 1. 100Mbps full-duplex 2. 100Mbps half-duplex 3. 10Mbps full-duplex 4. 10Mbps half-duplex Port F1 and F2 can be used as fiber uplink ports for connecting to another fiber optic device or operation as redundant function.
- Page 8 Speed LED Link/Activity LED Status No Connection Green Connect as 10Mbps Green Green Connect as 100Mbps 2.3.2.3 FDX/COL LED A collision occurs when two stations within a collision domain attempt to transmit data at the same time. Intermittent flashing amber of the collision LED is normal; the contending adapters resolve each collision by means of a wait-then-retransmit algorithm.
- Page 9 NOTE: The default primary is Port F2 and Secondary is Port F1. 2.4 The Rear Panel The rear panel of the hub is shown below 2.4.1 Power Connecting Plug the circle end of the power adapter firmly into the rear panel of the switching hub, and the other end into an electric service outlet then the system is ready.
- Page 10 Never stack units more than eight high if freestanding. Do not place objects on top of any unit or stack Do not obstruct any vents at the sides of the case 3.1.2 Installing Network Cables After placing the hub on the desktop, then we need to know how to connect the device to network.
- Page 11 4. Switch Operation MAC Address Table and Learning The switching hub is implemented with a MAC address table which is composed of many entries. Each entry is used to store the address information of network nodes on the network, including MAC address, port ID, etc. The information is the most important base to do packet filtering and forwarding.
- Page 12 5. Product Specifications Standard IEEE802.3, 10BASE-T IEEE802.3u, 100BASE-TX/FX Interface RJ-45 x8 NWay switching ports FO-SC or ST fiber connector x 2 Cable Connections RJ-45 (10BASE-T) : UTP Category 3,4,5 RJ-45 (100BASE-TX) : UTP Category 5 µ m multimode Fiber Optic :50/125, 62.5/125, or 100/140 µ...
