- Page 1 FOS-3110 Series 10-port L2+ Managed Gigabit Fiber Switch User’s Guide Version: 1.0...
-
Page 2: Revision History
This is a Class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. Trademarks CTS is a registered trademark of Connection Technology Systems Inc All trademarks belong to their respective proprietor Contents subject to change without prior notice. -
Page 3: Table Of Contents
Table of Contents Revision History ..................ii TABLE OF CONTENTS ................III CHAPTER1. INTRODUCTION ..........................2 1.1 O FOS-3110 ..............2 VERVIEW OF 1.2 K .................. 3 EATURES 1.3 F & R ................. 4 RONT ANELS 1.3.1 Front Panel ................4 1.3.2 Rear Panel ................ -
Page 5: About This Manual
About this manual In this user’s guide, it will not only clearly introduce CTS FOS- 3110 Managed Switch but tell you how to install this Managed Switch with detailed instructions. Organization of the Manual Chapter 1 “Introduction” describes the features of the Managed Switch ... -
Page 6: Chapter1. Introduction
Introduction Introduction CTS’s Managed Switch is designed to meet the emerging FTTX & Metro Ethernet requirements. Its low profile appearance with 1U height and the standard rack-mounted size achieve the highest density within a single rack. When massive fiber ports need to be deployed, the Managed Switch provides the best performance and price ratio. -
Page 7: Key Features
Introduction 1.2 Key Features 8.5 inch, 1U high 8 x 100/1000Base-X ports IEEE 802.3/802.3u/802.3ab/802.3z compliance Support Auto-Sensing for fiber ports Support MDI/MDIX/Auto-Crossover SFP Slot 2 x 10/100/1000Base-T, 100/1000Base-X Combo ports IEEE 802.3ab/802.3z Support Auto-Negotiation (RJ-45) and Auto-Sensing (SFP) Support MDI/MDIX/Auto-Crossover RJ-45 or SFP Slot ... -
Page 8: Front & Rear Panels
Introduction 1.3 Front & Rear Panels 1.3.1 Front Panel Figure 1-1. FOS-3110 Managed Switch Front Panel The interfaces on the front panel of the Managed Switch are described below: 8 x 100/1000Base-X SFP ports (Ports 1-8) 2 x Gigabit combo ports (Ports 9-10): ... -
Page 9: Rear Panel
Introduction 1.3.2 Rear Panel The Managed Switch provides one fixed power module. The type of power module is AC input. Figure 1-2. FOS-3110 Managed Switch Rear Panel The interface on the rear panel of the Managed Switch is described below: Power module and Connector: ... -
Page 10: Led Definitions
Introduction 1.4 LED Definitions The Managed Switch is Plug & Play compliant. The real-time operational status can be monitored through a set of LED indicators located in the front panel. Figure 1-3. LEDs of FOS-3110 Managed Switch Power LED The power status of the Managed Switch is indicated by the Power LED on the front panel of the device. - Page 11 Introduction COM LED The console status is indicated by the COM LED on the front panel of the device. Color Operation Either the console port is not activated or no session exists. Lit when the console port is activated and the session Green exists.
-
Page 12: Cable Specifications
Introduction 1.5 Cable Specifications The following table contains various cable specifications for the Managed Switch. Please make sure that you use the proper cable when connecting the Managed Switch. Cable Type Description UTP Category 3, 4, 5 (100 meters max.) 10Base-T EIA/TIA- 568 150-ohm STP (100 meters max.) UTP Cat. -
Page 13: Chapter 2. Installation
Installation Installation To properly install the FOS-3110 Managed Switch, please follow the procedures listed below. These procedures will be respectively described in detail in the following sections. Installation Requirements Checking the Package Contents Installing the Managed Switch ... -
Page 14: Installation Requirements
Installation 2.1 Installation Requirements Basic requirements for installation are as follows: Environmental conditions One power outlet Proper ventilation Proper isolation to electrical noise, radio, etc. UTP cables should not run in the same duct with power and phone line cables ... -
Page 15: Installing The Managed Switch
Installation 2.3 Installing the Managed Switch You can install the FOS-3110 switch on a flat surface or mount it in a standard 19-inch network equipment rack. CAUTION To prevent any damage or failure of the Managed Switch, please DO NOT block the ventilation holes. -
Page 16: Rack Installation
Installation 2.3.2 Rack Installation Either you can install an 8.5-inch switch or two 8.5-inch switches in a standard 19-inch network equipment rack. In the following sections, we will take the FOS-3110 Managed Switch for example to separately demonstrate how to mount it or them in this size of rack space. WARNING! Please mount the Switch firmly in rack, otherwise it may fall and cause the system damage and possible injury to personnel. - Page 17 Installation Step 3. Then, tighten the screws with the screwdriver to secure each bracket. Step 4. Align the mounting holes in the brackets with the desired holes in the rack, and insert screws through each bracket and into the rack. Step 5.
-
Page 18: Install Two Fos-3110 Switches In A Rack Using Fos Combine Kit
Installation 2.3.2.2 Install two FOS-3110 Switches in a Rack Using FOS Combine To install two sets of FOS-3110 in a single rack space, you need the 19-inch rack-mount kit as well as the FOS combine kit, supplied with the switch. Also follow the procedures listed below for step- by-step instructions to install your switches in this rack space: Step 1. - Page 19 Installation 2.4. On the left side of the switch, attach one ⼐-shaped fixed piece in the reverse direction by inserting the screws provided in the FOS combine kit through this fixed piece and into the mounting holes in the switch. (See Figure 2-3) 2.5.
- Page 20 Installation Step 6. Align the mounting holes in the regular brackets on both sides (the left side of the left switch and the right side of the right switch) with the desired holes in the rack, and insert the screws through each bracket and into the rack. Step 7.
-
Page 21: Install A Single/Two Fos-3110 Switches In A Rack Using 19-Inch Rack-Mount Bracket
Installation 2.3.2.3 Install a Single/Two FOS-3110 Switches in a Rack Using 19- inch Rack-mount Bracket Besides the mounting methods we previously mentioned, to install one or two sets of FOS-3110 in a single rack space; alternatively, you can use the 19-inch rack-mount bracket supplied with the switch. - Page 22 Installation 19-inch Rack- mount Bracket Figure 2-6. Install the19-inch rack-mount bracket for two-switch mounting Step 3. Align the mounting holes on both sides of this 19-inch rack-mount bracket with the desired holes in the rack, and insert the screws through this bracket and into the rack. Step 4.
-
Page 23: Powering On The Managed Switch
Installation 2.4 Powering on the Managed Switch The Managed Switch can be used with AC power supply 100-240 V, 50–60 Hz, 0.4A~0.2A. After the Managed Switch is turned on, the Power LED indicators should light in green color. For more details about the power LED description, please refer to Section 1.4 LED Definitions. -
Page 24: Chapter 3. Operation
Operation Operation A built-in management module of Managed Switch provides users flexible interfaces to configure, control and monitor the system remotely and locally. To know the further information about the operation of Managed Switch, please refer to FOS-3110 Network Management User’s Manual for the detailed management functions and required installation and operation procedures. - Page 25 Operation SNMP Management SNMP is also In-Band-Management and requires a network connection to the Managed Switch. The Managed Switch private Management Information Bases (MIB) is provided for SNMP-based network management program to configure, control and monitor the system. Web Management Web Management is done over the network.
-
Page 26: Maintenance
Maintenance Maintenance This Managed Switch is easy to maintain. The procedures are suggested when you would like to identify faults, perform hardware replacement and firmware upgrade. 4.1 Fault Identification Identifying faults can greatly reduce the times required to find problem and solution. Users may perform local check or remote check to find the problems. -
Page 27: Remote Check
Maintenance 4.1.2 Remote Check Users may check the Managed Switch through SNMP manager remotely. For detailed procedures, please refer to the Network Management User’s Manual. 4.2 Hardware Replacement Procedures WARNING! The Managed Switch contains no user-serviceable parts. DO NOT, UNDER ANY CIRCUMSTANCES, open and attempt to repair it. - Page 29 18F-6, No.79, Sec.1, Xintai 5th Rd., XiZhi Dist., New Taipei City 221, Taiwan(R.O.C) Tel: +886-2-2698-9661 Fax: +886-2-2698-9662 Dir.Line:+886-2-2698-9201 www.ctsystem.com...
