- Page 1 HES-3106-SE SERIES 5-PORT 10/100/1000BASE-T RJ-45 AND 1-PORT 100/1000BASE-X F/O MANAGED ETHERNET SWITCH WITH OPTIONAL CATV RF MODULE User’s Guide Version 1.0...
- Page 2 Trademarks CTS is a registered trademark of Connection Technology Systems Inc. Contents subject to revision without prior notice. All other trademarks remain the property of their respective owners. Copyright Statement Copyright 2022 Connection Technology Systems Inc.. This publication may not be reproduced as a whole or in part, in any way whatsoever unless prior consent has been obtained from Connection Technology Systems Inc.
- Page 3 Revision History Version Date Description 20220726 First Release...
- Page 4 Table of Contents 1. INTRODUCTION ................... 5 1.1 The Managed Ethernet Switch ..............5 1.2 Appearance ....................7 2. INSTALLATION ................... 10 2.1 Installation Requirements ............... 10 2.2 Checking the Package Contents ............10 2.3 Installing the Managed Switch ..............11 2.4 Powering on the Managed Switch ............
- Page 5 1. INTRODUCTION Thank you for choosing this Managed Ethernet Switch. The Managed Switch can provide the best performance and price ratio when multiple copper ports need to be deployed in networking environment. 1.1 The Managed Ethernet Switch With 5 x 10/100/1000Mbps RJ-45 ports on the front panel and 1 x 100/1000Mbps fiber port on the rear panel, this compact Managed Switch provides high performance store-and-forward switching capability plus other advanced features such as QoS, VLAN, etc.
- Page 6 QoS Support 802.1p and ToS Classification Priority Queues: 8 Queues Management: Telnet/SSHv2/SNMP/Web interface Storm Control DHCP Client DHCP Auto-Provisioning Text Based Config SFF-8472 (digital diagnostic management interface for SFP) Power Down Trap ...
- Page 7 1.2 Appearance Front Panel ➊ ➋ Figure 1. Front Panel for 5-Port 10/100/1000Base-T and 1-Port 100/1000Base-X Managed Ethernet Switch ➊ ➋ ➌ Figure 2. Front Panel for 5-Port 10/100/1000Base-T and 1-Port 100/1000Base-X Managed Ethernet Switch with CATV RF Module ➊ Power Jack Connector ➋...
- Page 8 Rear Panel Figure 3. Rear Panel for 5-Port 10/100/1000Base-T and 1-Port 100/1000Base-X Managed Ethernet Switch ➎ Figure 4. Rear Panel for 5-Port 10/100/1000Base-T and 1-Port 100/1000Base-X Managed Ethernet Switch with CATV RF Module 100/1000Mbps F/O Port 1 x fixed fiber for HES-3106BW2A(SM-10)-SE-DR series ...
- Page 9 Top Panel ➐ Figure 7. Top Panel of the Managed Switch ➐ LED: For detail definitions, please refer to chapter 3.1 LED Definitions Cable Specifications The following table contains various cable specifications for the Managed Switch. Please make sure that you use the proper cable when connecting the Managed Switch.
- Page 10 2. INSTALLATION To properly install the Managed Switch, please follow the procedures listed below. Procedures covered in this chapter are described below in separate sections. Installation Requirements Unpacking the Managed Switch Installing the Managed Switch Powering on the Managed Switch ...
- Page 11 2.3 Installing the Managed Switch CAUTION To prevent any damage or failure of the Managed Switch, please DO NOT block the ventilation holes. Use the following guidelines when choosing a place to install the Switch: Firm and steady flat surface. ...
- Page 12 2.5 Connecting the Switch to Network Connect to Network This Managed Switch has 5 x 10/100/1000Mbps RJ-45 ports on the front panel. These ports can be inserted by 10/100/1000Base-T cables, connecting to the end devices. The connection of the 1 x 100/1000Mbps fiber port on the rear panel must be matched, i.e.
- Page 13 3. OPERATION The Managed Switch is Plug & Play compliant. Real-time operational status can be monitored through a set of LED indicators located on the top panel. A built-in management module provides users with flexible interfaces to configure, control and monitor the complete system remotely. 3.1 LED Definitions Definition Color...
- Page 14 4. MAINTENANCE It is easy to use and maintain this Managed Switch. The procedures are suggested when you want to identify faults, perform hardware replacement and firmware upgrading. 4.1 Fault Identification Identifying faults can greatly reduce the time required to find the problem and solution.
- Page 15 4.2 Hardware Replacement Procedures WARNING! The Managed Switch contains no user-serviceable parts. DO NOT, UNDER ANY CIRCUMSTANCES, open and attempt to repair it. Failure to observe this warning could result in personal injury or death from electrical shock. Failure to observe the above warning will immediately void any Warranty. 4.3 Firmware Upgrade This Managed Switch may perform firmware upgrading when required.
