- Page 1 HES-5106 Series 6-port L2 Managed Fiber CPE Switch User’s Guide Version: 1.0...
-
Page 2: Revision History
This is a Class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. Trademarks CTS is a registered trademark of Connection Technology Systems Inc. All trademarks belong to their respective proprietors Contents subject to change without prior notice. -
Page 3: Cts Contact Information
CTS Contact Information Headquarters/Manufacturer: ▓ Connection Technology Systems Inc. 18F-6, No.79, Sec.1, Xintai 5th Rd., Xizhi Dist., New Taipei City 221, Taiwan(R.O.C.) Tel: +886-2-2698-9661 Fax: +886-2-2698-3960 Sales Direct Line:+886-2-2698-9201 www.ctsystem.com Global Offices: ▓ Connection Technology USA Connection Technology Systems Japan 40538 La Purissima Way, Higobashi Bldg. -
Page 4: Table Of Contents
Table of Contents Revision History ........................ii CTS CONTACT INFORMATION ..................III TABLE OF CONTENTS ....................IV CHAPTER 1. INTRODUCTION ................... 2 1.1 O HES-5106SFP+ ..................2 VERVIEW OF 1.2 K ........................ 3 EATURES 1.3 F & T & R .................. - Page 7 About this manual In this user’s guide, it will not only clearly introduce CTS HES-5106SFP+ Managed Switch but tell you how to install this Managed Switch with detailed instructions. Organization of the Manual Chapter 1 “Introduction” describes the features of the Managed Switch ...
-
Page 8: Chapter 1. Introduction
Introduction Introduction CTS’s Managed Switch is designed to meet the emerging FTTX & Metro Ethernet requirements. When massive fiber ports need to be deployed, the Managed Switch provides the best performance and price ratio. 1.1 Overview of HES-5106SFP+ HES-5106SFP+, a compact Managed Ethernet CPE Switch, has 5 RJ-45 ports (4 10/100/1000Base-T &... -
Page 9: Key Features
Introduction 1.2 Key Features 4 x 10/100/1000Base-T ports IEEE 802.3/802.3u/802.3ab Support Auto-Negotiation Support MDI/MDIX/Auto-Crossover RJ-45 Slot 1 x NBase-T port IEEE 802.3ab, 802.3bz, 802.3ae, and 802.3an Support Auto-Negotiation for 4-speed options (1G/2.5G/5G/10G) Support MDI/MDIX/Auto-Crossover Support Auto-Sensing for NBase-T port RJ-45 Slot ... - Page 10 Introduction Port Link Flap 4-level LED Intensity Control Support lan-follow-wan function Support DHCP Auto-Provision via DHCP option 60/43 for firmware and configuration Management Functions Telnet & SSH/CLI Web (HTTP & HTTPS) RADIUS for authentication SNMP v1/v2c/v3 and network management SNMP Power-Down Trap Private, RFC-1213, RMON MIBs Port mirroring...
-
Page 11: Front & Top & Rear Panels
Introduction 1.3 Front & Top & Rear Panels 1.3.1 Front & Top Panels Figure 1-1. HES-5106SFP+ Managed Switch Front Panel The interfaces on the front & top panels of the Managed Switch are described below: 4 x 10/100/1000Base-T RJ-45 ports (Ports 1-4) 1 x NBase-T (1G/2.5G/5G/10G) RJ-45 port (Port 5) Reset Button: Press the reset button for 5~10 seconds, then release it to restart the system. -
Page 12: Rear Panel
Introduction 1.3.2 Rear Panel Figure 1-2. HES-5106SFP+ Managed Switch Rear Panel The interface on the rear panel of the Managed Switch is described below: 1 x 1G/10GBase-R SFP+ UPLINK port (Port 6) Publication date: May 22, 2020 Revision 1.0... -
Page 13: Led Definitions
Introduction 1.4 LED Definitions The Managed Switch is Plug & Play compliant. The real-time operational status can be monitored through a set of LED indicators located on the front panel. Figure 1-3. LEDs of HES-5106SFP+ Managed Switch Color Operation Device is powered down or power is not installed. POWER Green Lit when this power is in normal operation. - Page 14 Introduction Lit when 10/100Mbps TP port link is up. Green Blinking when TP port is receiving and transmitting data at the speed of 10/100Mbps. No connection exists. Lit when 1000Mbps TP port link is up. Orange Blinking when this TP Port is receiving and transmitting data at the speed of 1000Mbps.
-
Page 15: Cable Specifications
Introduction 1.5 Cable Specifications The following table contains various cable specifications for the Managed Switch. Please make sure that you use the proper cable when connecting the Managed Switch. Cable Type Description Multi-mode fiber module(2km) / Single-mode fiber 100BASE-FX module 1000BASE-SX Multi-mode fiber module (550m) 1000BASE-LX... -
Page 16: Chapter 2. Installation
Installation Installation To properly install the HES-5106SFP+ Managed Switch, please follow the procedures listed below. These procedures will be respectively described in detail in the following sections. Installation Requirements Checking the Package Contents Installing the Managed Switch Powering on the Managed Switch ... -
Page 17: Installation Requirements
Installation 2.1 Installation Requirements Basic requirements for installation are as follows: Environmental conditions One power outlet Proper ventilation Proper isolation to electrical noise, radio, etc. UTP cables should not run in the same duct with power and phone line cables ... -
Page 18: Installing The Managed Switch
Installation 2.3 Installing the Managed Switch You can install the HES-3106SFP-F2 switch on a flat surface. CAUTION To prevent any damage or failure of the Managed Switch, please DO NOT block the ventilation holes. Use the following guidelines when choosing a place to install the switch: ... -
Page 19: Installing And Removing Sfp/Sfp+ Modules
Installation 2.6 Installing and Removing SFP/SFP+ Modules 2.6.1 Installing SFP/SFP+ Modules To connect the fiber transceiver and LC/SC cable, use the following guidelines: Position the SFP/SFP+ transceiver with the handle on top. 2. Locate the triangular marking in the slot and align it with the bottom of the transceiver. 3. -
Page 20: Operation
Operation Operation A built-in management module of Managed Switch provides users flexible interfaces to configure, control and monitor the system remotely. To know the further information about the operation of Managed Switch, please refer to HES-5106SFP+ Network Management User’s Manual for the detailed management functions and required installation and operation procedures. -
Page 21: Chapter 4. Maintenance
Maintenance Maintenance This Managed Switch is easy to maintain. The procedures are suggested when you would like to identify faults, perform hardware replacement and do the firmware upgrade. 4.1 Fault Identification Identifying faults can greatly reduce the times required to find problem and solution. Users may perform local check or remote check to find the problems. -
Page 22: Remote Check
Maintenance 4.1.2 Remote Check Users may check the Managed Switch through SNMP manager remotely. For detailed procedures, please refer to the Network Management User’s Manual. 4.2 Hardware Replacement Procedures WARNING! The Managed Switch contains no user-serviceable parts. DO NOT, UNDER ANY CIRCUMSTANCES, open and attempt to repair it. - Page 23 18F-6, No.79, Sec.1, Xintai 5th Rd., XiZhi Dist., New Taipei City 221, Taiwan(R.O.C) Tel: +886-2-2698-9661 Fax: +886-2-2698-9662 Dir.Line:+886-2-2698-9201 www.ctsystem.com...
