- Page 1 SWH-2108 8 Ports 10/100Base-TX Managed Ethernet Switch User's Guide Ver: 1.0...
- Page 2 Trademarks CTS is a registered trademark of Connection Technology Systems Inc. Contents subject to revise without prior notice. All other trademarks remain the property of their owners. Copyright Statement Copyright © Connection Technology Systems Inc. This publication may not be reproduced as a whole or in part, in any way whatsoever unless prior consent has been obtained from Connection Technology Systems Inc.
-
Page 3: Table Of Contents
Table of Contents UNPACKING INFORMATION ................4 INTRODUCTION TO 8 PORT N-WAY SWITCHING HUB ......5 .................. 5 ENERAL ESCRIPTION ....................5 EATURES ..................6 RONT ANEL 2.3.1 System LEDs....................7 2.3.1.1 Power LED ......................7 2.3.2 Port LEDs....................... 7 2.3.2.1 Speed LED ...................... -
Page 4: Unpacking Information
1. Unpacking Information Thank you for purchasing the 8-port SWH-2108 N-Way switching hub. Before you start, please check all the contents of this package. The product package should include the following: 1. One 8-port N-Way switching hub 2. One external power supply 3. -
Page 5: Introduction To 8 Port N-Way Switching Hub
This device is a powerful, high-performance Ethernet / Fast Ethernet Switch. Twisted pair ports are capable of 10 or 100Mbps auto-negotiation operation (N-Way). The SWH-2108 is an ideal solution for micro-segmenting large networks into smaller sub-networks for overall improved performance, so enabling the most demanding bandwidth multimedia and imaging applications. -
Page 6: The Front Panel
Support Port Based VLAN Support 802.1Q Tagged VLAN State Monitor – Model / Media / Link / Speed / Duplex Enhanced Port Monitor-Traffic Counter Switch port configuration- Auto / Speed / Duplex / Auto MDI/MDIX Support SNMP, Telnet and Console management FTP/TFTP firmware upgrade Time Server Configuration User Authentication... -
Page 7: System Leds
2.3.1 System LEDs System LED indicators are located on the front panel for showing the operating status of the whole device. 2.3.1.1 P OWER This indicator lights green when the hub is receiving power; otherwise, it is off. 2.3.2 Port LEDs Port LED indicators are located on the front panel for showing the operating status of each port. -
Page 8: The Rear Panel
Operation 100M 100Mbps (Green), 10Mbps (Off) Link/Act Link is present (Green), Activity (Blinking Green) FDX/COL Full-Duplex (Amber), Half-Duplex (Off), COL (Blinking Amber) 2.4 The Rear Panel The rear panel of the hub is shown below 2.4.1 Power Connecting Plug the circle end of the power adapter firmly into the rear panel of the switching hub, and the other end into an electric service outlet then the system is ready. -
Page 9: Installing And Using 8 Port N-Way Switching Hub
3. Installing and Using 8 Port N-Way Switching Hub 3.1 Installing the 8 Port N-Way Switching Hub The SWH-2108 does not require software configuration. Users can immediately use any of the features of this product simply by attaching the cables and turning the power 3.1.1 Desktop Installation... -
Page 10: Switch Operation
4. Switch Operation 4.1 MAC Address Table and Learning The switching hub is implemented with a MAC address table which is composed of many entries. Each entry is used to store the address information of network nodes on the network, including MAC address, port ID, etc. The information is the most important base to do packet filtering and forwarding. -
Page 11: Product Specifications
5. Product Specifications Standard IEEE802.3, 10BASE-T IEEE802.3u, 100BASE-TX Interface RJ-45 x 8 N-Way switching ports Cable Connections RJ-45 (10BASE-T) : UTP Category 3,4,5 RJ-45 (100BASE-TX) : UTP Category 5 Network Data Rate Auto-negotiation (10Mbps, 100Mbps) Transmission Mode Auto-negotiation (Full-duplex, Half-duplex) LED indications System Power x1...
