FALCON RIDGE MAH-ROXOR-RCC01 Instructions For Installation And Care

Mahindra roxor soft rear cargo cover

Download this manual

Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.

1. Be sure to read these instructions thoroughly before opening and installing the enclosure. The

installation is best done when the temperature is 70 degrees F. or warmer. The temperature affects the

adhesive Velcro, if conditions prevent installing in warmer weather it helps to store the adhesive Velcro

at room temperature prior to installation.

2. Carefully open the carton and remove the enclosure on a large flat surface that is clean and free of dirt.

3. Check over the parts included in the carton with the parts list shown below:

Adhesive Velcro Hook Strips:

Cab Enclosure

The cab will be put together using the following parts and in this order.

1) Rear Side Panels

2) Rear Cargo Cover

REAR SIDE PANELS

2515 Bypass Rd. Flemingsburg, KY 41041

606-845-7439

Instructions for Installation and Care of

Mahindra Roxor

Soft Rear Cargo Cover

MAH-ROXOR-RCC01

Rear Cargo Cover

2 each------------52"

1 each------------45"

2 each------------32"

3 panels

Page 1 Instructions for Installation and Care of Mahindra Roxor Soft Rear Cargo Cover MAH-ROXOR-RCC01 Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable. 1. Be sure to read these instructions thoroughly before opening and installing the enclosure. The installation is best done when the temperature is 70 degrees F.
Page 2 1. The Rear Side Panels are very simple to install. Take the 52” adhesive strips and install them on the top of the rear downbars as shown in the photo below 2. Now just line up the top corner so it overlaps the Velcro sewn to the outside of the door and attach it to the door and the roll cage.
Page 3 Cleaning and Storage Recommendations: 1. Before removing the Falcon Ridge Cab for storage, make sure it is very clean in order to prevent scratching of the window panels. Clean with a soft rag or sponge using a mild liquid detergent soap and warm water solution.
Page 4 Cab to either extreme hot or cold temperatures when storing. 3. A special cleaner conditioner is available from Falcon Ridge that will greatly increase the service life of the Cab Enclosure. In addition, if additional hook and loop sets are needed, they can also be ordered.
