SPECIFICATION

Code
Model
Rating
Power
Air Flow
Noise Level
Particle Size
Hose Diameter
Bag Capacity
Overall L x W x H
Weight
ASSEMBLY
Please read through the section entitled Parts Identification and Description, this will enable you to more readily
identify those parts of the cyclone extractor.
Please note: some of this assembly procedure is best accomplished by two persons. Although
the tasks are not impossible, some of the items are heavy and awkward, and a mishandling
error could cause injury. Please think about what you are doing, your capabilities and your
personal safety. We have added the 'two person symbol' to any operation that we recommend
should be a two person task.
Unpack all the boxes and check all the components listed in the "What's Included" section. If any parts or components are missing,
please contact our Customer Services Department using the procedures and telephone numbers listed in our catalogue.
Please note: on occasions the packing list is not strictly adhered to. Please check all the boxes, packets
etc. to make sure that all the parts have been accounted for.
PLEASE RECYCLE ANY UNWANTED PACKAGING RESPONSIBLY!
107632
AP60E
Professional
0.75kW 230V 1ph
850 m³/h at 100 mm
1 Meter (Distance) 77.6dB
3 Meter (Distance) 73.3dB
1 micron
100 mm
60 litre
720 x 660 x 1460 mm
27 kg
Code
Model
Rating
Power
Air Flow
Noise Level
Particle Size
Hose Diameter
Bag Capacity
Overall L x W x H
Weight
8
107633
AP170E
Professional
1.5kW 230V 1ph
2,250 m³/hr at 175 mm,
1,200 m³/hr at 100 mm
1 Meter (Distance) 80.2dB
3 Meter (Distance) 81dB
1 micron
1 x 175mm, 2 x 100 mm
170 litre
1,100 x 680 x 1,750 mm
56 kg
