Having unpacked the boxes, put all components where they
are readily to hand.
1. Locate the base (1-14), twelve UNC short bolts (12j - 27i) and
upright supports (3-16). Place one of the supports (3-16) on to
base and line up the pre-drilled holes with the ones to the side
of the base, lightly secure in place with two UNC bolts, see fig
01-02-03. Repeat for the remain support.
Note: Make sure the two holes to the top of the
supports face outwards!
Fig 01-02-03
12j
27i
14
2. Locate the tube support bar (2-17), line up the two holes
with the holes to the front of base (1-14) and lightly secure
using two UNC short bolts, see fig 04-05-06.
Fig 04-05-06
2
16
3
1
note: You will require assistance for the next
step!
3. Locate the extractor assembly (13-28), lower the assembly
down and insert the two upright supports into the extractors
mounting brackets to either side of the assembly,
see fig 07-08-09.
4. Line up the holes and secure in place using four UNC short
bolts (12j-27i) and the supplied spanner, 09-10.
Mounting bracket
12j 27i
17
9
12j 27i
13
ASSEMBLY
Fig 07-08
28
Fig 09-10
