2. Technical Specification

The following information represents the dimensions and weight information and the
manufacturer's approved machine data.

2.1 Specification

2.2 Dimensions

MODEL NO.
M o o t ( r W )
Motor speed 50Hz (RPM)
Motor speed 60Hz (RPM)
Impeller size(MM)
Inlet hole size(MM)
Number of Intake holes(MM)
Bag size(MM)
Bag volume (m³)
Air speed 50Hz (m³/h)
Air speed 60Hz (m³/h)
Filter area(m²):
Filter capacity (Micro)
Noise level (dB)
Width X Depth X Height(MM)
Packing size(MM)
FM330C-2000H
1 5 0 0 W
2850r/min
3450r/min
Φ330mm
Φ150mm
3XΦ100mm
Φ500x1100mm
0.216 m³
1450 m³/h
1500 m³/h
2.6 m²
1
84 dB
1200X660X1750
1020×590×900mm
1240×412×170mm
650×430×430mm
6
