3. Jumper Setting
JP1
JP2
JP3
JP4
JP5
* For more information, please refer to a Circuit Schematic.
4. Additional Documentation and User Support
The following documents and other supports are available at
http://www.hdl.co.jp/en/spc/UTL/utl-101/
Circuit Schematic
Pin List
Dimensional drawing
PCB drawing
... and more.
UTL-101 Series v1.0
Function
3.3 V to V33H
3.3 V to V33A
3.3 V to V33B
3.3 V to V33C
3.3 V to V33D
4
Default
Short
Short
Short
Short
Short
