1. Specifications

Model Name
I/F Connector
Power Input
Power Circuit
PCB
Dimensions
Weight
Operating Temp. Range
RoHS Compliance
* HSMC connector is high-speed board-to-board connector specification specified
by Altera.
(Related link: http://www.altera.com/literature/ds/hsmc_spec.pdf)
UTL-101 Series v1.0
UTL-101
2 HSMC connectors *
Stabilized DC 5 [V]
DC Jack (dia. 2.1 [mm], center plus)
3-position terminal block
3.3 [V] 10[A]
12 [V] 700 [mA] (ON/OFF switch)
4 Layer FR-4 t1.6 [mm] Immersion gold
6.102" x 5.669" (155 x 114 [mm])
130 [g] Typ.
0 to 40 [°C] (32 to 104 [°F])
YES
