Memory Map

Memory Map
The ADSP-BF592 processor has a single unified 4G memory space for
instructions and data storage. See
The processor's memory details can be found in the ADSP-BF59x Blackfin
Processor Hardware Reference Manual.
Table 1-1. ADSP-BF592 Processor Memory Map
Start Address
0xFFFF FFFF
0xFFE0 0000
0xFFC0 0000
0xFFB0 1000
0xFFB0 0000
0xFFA2 0000
0xFFA1 0000
0xFFA0 8000
0xFFA0 0000
0xFF80 8000
0xFF80 0000
0xEF00 1000
0xEF00 0000
1-12
Table
Content
CORE MEMORY MAPPED REGISTERS (2M BYTES)
SYSTEM MEMORY MAPPED REGISTERS (2M BYTES)
RESERVED
INTERNAL SCRATCHPAD RAM (4K BYTES)
RESERVED
L1 ROM (64K BYTES)
RESERVED
INSTRUCTION BANK SRAM (32K BYTES))
RESERVED
DATA BANK SRAM (32K BYTES)
RESERVED
BOOT ROM (4K BYTES)
RESERVED
ADSP-BF592 EZ-KIT Lite Evaluation System Manual
1-1.
