Strikeit1V Terminal Identification; Compatible Panic Hardware Devices; Maximum Wiring Distance Table - Altronix StrikeIt1V Installation Manual

Terminal Legend
L, G, N
+ 12VDC –
+ 24VDC –
+ BAT –
– OUT 1 +
– OUT 2 +
FACP / GND
IN1 / GND
IN2 / GND
Delayed 1
Delayed 2
Follower 1
Follower 2
Supervision
Manufacturer
First Choice
Kawneer
®
Von Duprin
HES
A maximum 0 .25 Ohm resistance of connecting wires is acceptable, see chart below for wire gauge and distances .
Wire Gauge
14 AWG Stranded
12 AWG Stranded
10 AWG Stranded
- 6 -

StrikeIt1V Terminal Identification:

Function/Description
Connect 220VAC, 50/60 Hz to these terminals: L to Hot, N to Neutral .
12VDC Auxiliary Output @ 0 .75A in alarm, 0 .5A in stand-by .
24VDC Auxiliary Output @ 0 .75A .
20VDC to 26 .4VDC for applications with battery back-up .
24VDC Stand-by Battery Connection (Two (2) 12VDC batteries wired in series) .
Connect 24VDC Panic Hardware Device #1 (See compatibility chart for other UL Listed
devices. Operating range of the device must cover 20VDC to 26.4VDC range 0.25 Ohm
maximum wiring resistance) .
Connect 24VDC Panic Hardware Device #2 . (See compatibility chart for other UL
Listed devices. Operating range of the device must cover 20VDC to 26.4VDC range 0.25
Ohm maximum wiring resistance) .
Normally Closed Dry Contact from Fire Alarm Control
(100 Ohm maximum wiring resistance) .
Normally Open Trigger input controls Output 1 . May be held closed for extended unlocking
(100 Ohm maximum wiring resistance) .
Normally Open Trigger input controls Output 2 . May be held closed for extended unlocking
(100 Ohm maximum wiring resistance) .
Dry form "A" contacts provide a 1 second momentary pulse after a preset delay . With DIP
switch [SW3] in the OFF position, the delay is 0 .5 seconds . With DIP switch [SW3] in
the ON position, the delay is 1 second (Fig. 3b, pg. 9) . This permits the Panic Hardware
Device to fully unlock before signaling auto operator to swing door .
Dry form "A" contacts provide a 1 second momentary pulse after a preset delay . With DIP
switch [SW3] in the OFF position, the delay is 0 .5 seconds . With DIP switch [SW3] in
the ON position, the delay is 1 second (Fig. 3b, pg. 9) . This permits the Panic Hardware
Device to fully unlock before signaling auto operator to swing door .
Dry form "A" contact . Energizes while output 1 is energized .
Enables outside ADA switch plate to actuate auto operator while door is unlocked .
De-activates outside ADA actuator while door is locked .
Dry form "A" contact . Energizes while output 2 is energized .
Enables outside ADA switch plate to actuate auto operator while door is unlocked .
De-activates outside ADA actuator while door is locked .
Indicates low DC output voltage condition .
It may be caused by an AC brownout and low battery occuring simultaneously .
Manual self test needs to be conducted to determine battery condition .

Compatible Panic Hardware Devices:

Model Number
3600 - Concealed Vertical Rod Exit Device
3700 - Rim Latching Exit Device
EL Paneline Exit Device
EL98 Series Panic Hardware with Electric Latch Retraction
7500 Electric Strike

Maximum Wiring Distance Table:

Distance
40 ft .
60 ft .
100 ft .
StrikeIt1V
