Danfoss ET4001 Crimp machine operator's manual
Shop/Work table mounting
ET4001 Press and pump
Shop/Work table
mounting instructions*
Figure 1
Bench layout for
ET4001 press
Figure 2
Lifting hole layout on ET4001
press top plate
Figure 3
ET4001P-002 Outlet port
IT IS RECOMMENDED
THAT THE PUMP BE ON
AN INDIVIDUAL 20 AMP
SERVICE OUTLET.
4 | © Danfoss ET4001 Crimp machine operator's manual | 2022.06.
The following methods are offered
as a guide and may be varied to
suit your particular needs.
1. Prepare mounting surface for
ET4001 press and pump. Refer
(Figure 1) for bolt hole layout
and optimum height.
IMPORTANT: Care must
be taken to insure that the
surface to which the press is
bolted is capable of supporting
the weight of the press
(approximately 500 lbs.) and
pump (approximately 75 lbs).
2. Remove shipping carton from
ET4001 press. There are four
/
-18 tapped holes in the top
5
8
Instructions
7. Standing behind the press,
install the # 8ORB x ORFS
fitting into the top port of the
crimper (Figure 4).
8. Screw the 90º end of the
T-410-22 hose loosely onto the
adapter installed in the top
port (Figure 4).
9. Remove the 08ORB plug
from the D05 valve manifold
mounted on the pump. Install
the 90º ORB x ORFS adapter.
Loosely install the straight end
of the T-410-22 hose assembly.
Note, you will need to orient
the elbow fitting in a slight
angle so the hose assembly
clears the D05 valve (Figure 6).
10. Standing at the back of the
machine, remove the #4
pipe plug from the center
of valve manifold. Install the
straight pipe nipple into the
pump. Then install the #4 size,
90º elbow onto the straight
adapter and the gauge into the
female port of the 90º elbow
fitting (Figure 5).
plate which may be used for
lifting purposes (Figure 2). If
these tapped holes are used,
it is recommended that a
minimum of two be utilized,
preferably four. If two holes
are used for lifting, use holes
directly across from each other
on the center line and not two
on a diagonal. This will prevent
press from tilting as it is raised.
3. Using an adequate lifting
device, raise the press to the
mounting surface. Align holes
in press support brackets with
holes in mounting surface.
Insert four ½" bolts from top
of mounting surface. Washers
and nuts are installed from
11. Tighten all fitting connections.
12. Remove the tank plug and
screw in reservoir vent cap.
Screw black cord into switch
on shroud (Figure 3). Plug
electrical plug into 220 volt 20
amp circuit.
*NOTE: When using
Cart (part number FF 91042)
holes are pre-drilled. See page
5 for photo.
underneath. TIGHTEN.
4. Place the ET4001P-002 pump
on the mounting surface to
the right and slightly behind
the ET4001 press. (Reference
figure 8, Page 5)
5. Mark power unit base plate
hole pattern on mounting
surface. Remove power unit
and drill holes.
6. Replace pump and align holes
on mounting surface with base
plate of pump. Insert bolts
from top of mounting surface.
Washers and nuts are installed
from underneath. TIGHTEN.
Figure 4
Connection at top plate
Figure 5
Gauge installation
Figure 6
Hose connection
AQ418954741547en-000101
