Danfoss ET4001 Crimp machine operator's manual
Specifications and equipment
ET4001 Crimp machine and accessories
AQ418954741547en-000101
ET4001 Crimp machine
ET4001 is ideal for factory high performance machine operations,
construction and mine locations. The ET4001 press offers crimping
capabilities through 2" I.D. six spiral hose.
Weight
Size
ET4001P-002 Electric pump
The Danfoss ET4001P-002 power unit is ideally suited for use with
the ET4001 press. It features a two-stage pump providing high flow
at low pressure for fast ram approach and low flow at high pressure
for actual crimping.
Dimensions
Weight
Pressure
Reservoir capacity
Outlet port size
Motor
Hydraulic oil
Flow
! CAUTION
The ET4001P-002 Electric pump has the relief valve set
at 5,000 psi. Damage to the press will result and the warranty may
be voided if higher pressures are used. Requires individual 20 amp
service breaker (220 v).
Components needed: T-410-22 hose assembly (1)
included in ET4001-004 package
© Danfoss ET4001 Crimp machine operator's manual | 2022.06. | 3
500 lbs.
30"high, 22"deep, 12"wide
7½" high, 10" wide, 22" long
75 lbs.
5000 psi
6 Quarts
¾-16 Straight thread O-ring
1HP, 3450 RPM, 220 volts, 60 cycle, Single Phase
ISO 32 (SAE 10W)
2.6 GPM to 900 psi. 0.6 GPM above 900 psi
