XVME-976 Adapter Module
Installation to Carrier Card
For proper installation, refer to Chapter One for Type B module assembly to
the XVME-976.
XVME-976 Installation
Figure 4-4 shows the front panel assembly of the XVME-976 memory ex-
pansion module.
Figure 4- 4. XVME-976 Memory Expansion Module Front Panel Assembly
4- 4-16
