Parallel Port Configuration And Connection - Xycom XVME-976/202 Manual

mode. It is the responsibility of the user's software to provide a protocol that
can handle the bi-directional nature of the interface. The four handshake in-
put signals (RI, CTS, DSR, and DCD) are tied active by the jumpers in-
stalled at W11, W12, W13, and W14 when this port is configured for RS-
485 (refer to Tables 2-10 and 2-11).

Parallel Port Configuration and Connection

Table 2-16 lists the connector pin assignments for the parallel port at J3. In
addition to the pins of connector J3, Table 2-16 also lists the corresponding
pins for the DB25F parallel connector cable supplied with the unit. The
pinout of J3 is such that it allows the use of a flat ribbon cable between J3
and a PC/AT compatible DB25F parallel connector.
Signal Name
-STROBE
Data 0
Data 1
Data 2
Data 3
Data 4
Data 5
Data 6
Data 7
-ACK
BUSY
PAPER EMPTY
SEL OUT
-AUTOFD
-ERROR
-INIT
-SEL IN
-POE
GND
Table 2-16. J3 Pin Assignment
Function
Output data strobe
Data bit (LSB)
:
:
:
:
:
:
Data bit (MSB)
Character accepted
Cannot receive data
Out of paper
Printer selected
Auto feed
Printer error
Initialize printer
Selects printer
Port output enable
Signal ground
Chapter 2 – SSP Installation (XVME-956/400)
In/Out J3 Pin
out 1
I/O 3
I/O 5
I/O 7
I/O 9
I/O 11
I/O 13
I/O 15
I/O 17
in 19
in 21
in 23
in 25
out 2
in 4
out 6
out 8
in 26
--- 10, 12
14, 16
18, 20
22, 24
DB25f Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
--
18-25
2-9
