XVME-976 Adapter Module
8
7
6
O Hardware Interrupts Enabled
C Hardware Interrupts Disabled
O = Open
C = Closed
Partitioning and Formatting
A utility program named AFDISK is provided to partition and format SCSI
drives which are installed under the drivers. Use this utility to:
Partition SCSI drives into logical disks. Multiple partitions can be cre-
ated on one physical drive.
Format SCSI logical drives or partitions.
Delete existing partitions.
AFDISK provides the functional equivalent of the DOS FORMAT and
FDISK utilities. Use AFDISK on drives to be installed under the drivers, do
not use DOS utilities.
AFDISK Operation
Locate the diskette shipped with the module and copy the five files in the
AFDISK subdirectory into a working subdirectory.
To run AFDISK, simply type AFDISK at the DOS prompt. Follow the di-
rections on the screen to partition and format the selected SCSI devices. By
pressing the F1 key, the AFDISK utility also provides on-line help.
By pressing the ESC key, the AFDISK utility may be exited at any time
without executing any changes.
Reboot the system once the SCSI device(s) are partitioned and formatted.
This step saves any changes made and allows use of the newly installed
disk(s) or partition(s) by the aspidisk.sys utility.
3-6
Table 3-2. Switch 2 Description
5
4
O I/O Base Address = 34h
C I/O Base Address = 14h
O
O Interrupts Level 11
O
C Interrupts Level 12
O Interrupts Level 10
C
C Interrupts Level 9
C
3
2
1
O
O
O
O
O
C
O
C
O
O
C
C
C
O
O
C
O
C
C
C
O
C
C
C
BIOS Loca-
tion
Disabled
DC000
D8000
D4000
D0000
CC000
C8000
Disabled
