XVME-976 Adapter Module
Installing the PMC Module onto the XVME-976 Adapter
Module
This procedure assumes the XVME-976 is attached to either the
XVME-654 or XVME-655 module. Procedures for installing
the XVME-976 onto those modules can be found earlier in this
chapter.
1. Follow procedures for the prevention of static discharge to prevent dam-
age to the circuitry of the modules.
2. Disconnect all power sources.
3. Loosen the screws on the front panel of the XVME processor module.
4. Remove the XVME-976 and any attached modules from the VME back-
plane, as follows:
5. Place the XVME-976 (and any attached boards) on a static-free surface
with the XVME-976 on top. See Figure 1-5.
6. Pop out the filler plate in the XVME-976 front panel.
7. Align the PMC board with the 5-volt key. See Figure 1-5.
8. Insert the four screws to secure the expansion module to the XVME-976.
9. Align the connected modules (with the XVME-976 on the right) on the
plastic guides in the slots.
10. Gently push the modules to the rear of the chassis until the P1 and P2
connectors engage.
11. Tighten the screws on the front panel of the XVME processor module to
secure the connected modules into place. The installation is complete.
1-12
Note
•
Gently pull on the face plate(s) until the board(s) slide out of the
chassis
