Over Armour Offroad
NOTICE: Please check contents of package for any damage and make sure all parts fit correctly
and you are happy with the product before removing protective film. Once the film is removed
1. Be sure to read these instructions thoroughly before opening and installing the Can Am Areo-
Vent Polycarbonate Windshield.
2. Check over the parts included in the cartons with the parts list shown below:
2" Loom Clamps------------------------6 each
1" Stainless Steels Bolts--------------12 each
Stainless Steel Washers---------------16 each
Plastic Thumb Nuts---------------------8 each
Lock Nuts--------------------------------4 each
Slide Fasteners---------------------------8 each
50" Rubber Gasket----------------------1 each
Polycarbonate Brace--------------------1 each
Polycarbonate Vent Sliders------------2 each
Polycarbonate Windshield-------------1 each
3. Start by pulling it out of the box and find a clean area to lay it down and install the hardware.
Begin by peeling off the protective film. Next take the 50" piece of rubber gasket and starting at
one end firmly place across the bottom of the windshield. You may need to trim off excess
gasket. The diagram below shows where to install the gasket.
2515 Bypass Rd. Flemingsburg, KY 41041
606-845-7439
Instructions for Installation and Care of
Can Am Aero-Vent Polycarbonate Windshield
Can-1000-WD05
you cannot return the product for a full refund.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Can-1000-WD05 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Over Armour Offroad Can-1000-WD05

  • Page 1 Over Armour Offroad 2515 Bypass Rd. Flemingsburg, KY 41041 606-845-7439 Instructions for Installation and Care of Can Am Aero-Vent Polycarbonate Windshield Can-1000-WD05 NOTICE: Please check contents of package for any damage and make sure all parts fit correctly and you are happy with the product before removing protective film. Once the film is removed you cannot return the product for a full refund.
  • Page 2 4. Next install the sliding vent panel on the inside of the windshield as shown in the diagram below. To install slide fasteners, push through holes with thumbs until it is completely through the hole in the windshield and locked in place.
  • Page 3 5. Now the Windshield is ready to be installed. With the help of a friend, place the Windshield on the Commander, setting it up onto the hood. 6. Take the remaining hardware and install the windshield to the roll cage as shown in the diagram below.
  • Page 4 7. Now you can install the top brace if you want. If you do not have an Over Armour Offroad Cab enclosure to work with this windshield, the top brace is not needed but can be installed for extra strength. Below is a diagram showing how the brace is to be installed.
  • Page 5 9. Now you are ready to take it out and enjoy. To clean the windshield, always clean using a liquid of some sort to decrease the chance of scratches. We recommend using micro fiber cloths that are readily available at any dollar store. Any window cleaner will work fine; just remember to use a soft clean rag or micro-fiber cloth to clean it.
  • Page 6 Completed Windshield –Inside view...
  • Page 7 - a 20% restocking fee will apply. If ordered from Over Armour Offroad please call at 606-845-7439 to gain a return authorization number, use our preferred shipping carrier (UPS) to return the item (unless the item is defective, you are responsible for paying the shipping to return the item.) Any...
  • Page 8 2515 Bypass Rd, Flemingsburg, KY 41041 Phone: 606-845-7439 To The Owner of this Product: Thank you for purchasing one of Over Armour Offroad Cab Enclosures &/or Windshields! Below are the terms under which your product is covered under our manufacturer’s warranty.
