NOTICE: Please check contents of package for any damage and make sure all parts fit
correctly and you are happy with the product before removing protective film. Once the
film is removed you cannot return the product for a full refund.
1. Be sure to read these instructions thoroughly before opening and installing the John
Honda Pioneer 700 and 700/4 Aero-Vent Polycarbonate Windshield.
2. Check over the parts included in the cartons with the parts list shown below:
1 5/8" Loom Clamps
1" Stainless Steels Bolts
Stainless Steel Washers
Plastic Thumb Nuts
Lock Nuts
Slide Fasteners
52" Rubber Gasket
Polycarbonate Brace
Polycarbonate Vent Slider
Polycarbonate Windshield
3. Start by pulling it out of the box and find a clean area to lay it down and install the
hardware. Begin by peeling off the protective film. Next take the 52" piece of rubber
gasket and starting at one end firmly place across the bottom of the windshield. You may
need to trim off excess gasket. The diagram below show where to install the gasket.
Diagram Not Pioneer 700
2515 Bypass Rd. Flemingsburg, KY 41041
606-845-7439
Instructions for Installation and Care of
Honda Pioneer 700 and 700 4
Aero-Vent Polycarbonate Windshield
HO-700-WD05
8 each
13 each
17 each
9 each
4 each
4 each
1 each
1 each
1 each
1 each
