Over Armour Offroad
Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
1. Be sure to read these instructions thoroughly before opening and installing the Textron
Stampede 4 Soft Door Rear Window Combo. The installation is best done when the
temperature is 70 degrees F. or warmer. The temperature affects the adhesive Velcro, if
conditions prevent installing in warmer weather it helps to store the adhesive Velcro at
room temperature prior to installation.
2. Carefully open the carton and remove the enclosure on a large flat surface that is clean
and free of dirt.
3. Check over the parts included in the carton with the parts list shown below:
Adhesive Velcro Hook Strips:
"
"
Snap Screw Studs
---------------------------------------------------------------------------
Adhesive Velcro Hook Strips:
"
Snap Screw Studs
The cab for you Stampede is made up of 4 different components that work together to enclose
your vehicle. Install the cab in the following order.
1) Soft Doors
Soft Doors
2515 Bypass Rd. Flemingsburg, KY 41041
606-845-7439
Instructions for Installation and Care of
Textron Stampede 4
Soft Door Rear Window Combo
TX-STAMP-4-DRW01
"
"
"
"
"
"
"
"
"
Soft Doors
28 each------------3"
2 each------------32"
21 each ( 1 extra )
Rear Window
2 each------------16"
3 each
Advertisement
Table of Contents
Related Manuals for Over Armour Offroad TX-STAMP-4-DRW01
Summary of Contents for Over Armour Offroad TX-STAMP-4-DRW01
- Page 1 Over Armour Offroad 2515 Bypass Rd. Flemingsburg, KY 41041 606-845-7439 Instructions for Installation and Care of Textron Stampede 4 Soft Door Rear Window Combo TX-STAMP-4-DRW01 Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
- Page 2 1. Begin by holding the door up to the frame and attach it using the double-sided Velcro strips sewn perpendicular to the edge of the door. At each of the double-sided strips take one of the 3" adhesive Velcro strips and adhere it to the inside of the frame. Then wrap the double-sided strip around it so that the adhesive strip holds it firmly in place.
- Page 3 2. Next take the 30" adhesive Velcro strips and run it down the back of the roll cage facing towards the rear of the vehicle. Start at the bottom and work your way up the bar. You will see the double-sided Velcro tabs sewn along the back of the doors that will attach to this strip.
- Page 4 3. Next place two 3” adhesive strip on the center bar towards the bottom to match up with the two tabs as shown in the photo below. 4. Last piece of Velcro is the 3” strip on the end of the front strip as shown in the photo below.
- Page 5 Then push them into the plastic to make an mark. Then pull the screw stud out and screw it into the plastic where the mark was made. See Photos Below. 6. Final step on the doors are to install the polycarbonate panel in the hole at the bottom of the factory half door.
- Page 6 REAR WINDOW 7. Begin by placing the two 16" adhesive Velcro strip across the top of the roll cage. Make sure to place them on top of the bar on both sides of the rear brake light. Photo below shows how it should look. 8.
- Page 7 9. The bottom of the Rear Window is held in place by 3 snaps. Photo below shows how this should go. Cleaning and Storage Recommendations: Before removing the Over Armour Cab for storage, make sure it is very clean in order to prevent scratching of the window panels.
