Over Armour Offroad
Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
1. Be sure to read these instructions thoroughly before opening and installing the Textron
Stampede 4 Full Cab fits Poly Windshield. The installation is best done when the
temperature is 70 degrees F. or warmer. The temperature affects the adhesive Velcro, if
conditions prevent installing in warmer weather it helps to store the adhesive Velcro at
room temperature prior to installation.
2. Carefully open the carton and remove the enclosure on a large flat surface that is clean
and free of dirt.
3. Check over the parts included in the carton with the parts list shown below:
Adhesive Velcro Hook Strips:
"
"
Polycarbonate Door Panel
Panel Screws
Snap Screw Studs
---------------------------------------------------------------------------
Adhesive Velcro Hook Strips:
"
Snap Screw Studs
---------------------------------------------------------------------------
36" Webbing Straps w/ Loop
The cab for you Stampede 4 is made up of 4 different components that work together to enclose
your vehicle. Install the cab in the following order.
1) Soft Doors
2) Rear Window
4) Top Cap
2515 Bypass Rd. Flemingsburg, KY 41041
606-845-7439
Instructions for Installation and Care of
Textron Stampede 4
Full Cab fits Aero-Vent Poly Windshield
TX-STAMP-4-FC04
"
"
"
"
"
"
"
"
"
Soft Doors
28 each------------3"
2 each------------32"
2 each
8 each
21 each ( 1 extra )
Rear Window
2 each------------16"
3 each
Top Cap
4 each
Advertisement
Related Manuals for Over Armour Offroad TX-STAMP-4-FC04
Summary of Contents for Over Armour Offroad TX-STAMP-4-FC04
- Page 1 Over Armour Offroad 2515 Bypass Rd. Flemingsburg, KY 41041 606-845-7439 Instructions for Installation and Care of Textron Stampede 4 Full Cab fits Aero-Vent Poly Windshield TX-STAMP-4-FC04 Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
- Page 2 Soft Doors 1. Begin by holding the door up to the frame and attach it using the double-sided Velcro strips sewn perpendicular to the edge of the door. At each of the double-sided strips take one of the 3" adhesive Velcro strips and adhere it to the inside of the frame. Then wrap the double-sided strip around it so that the adhesive strip holds it firmly in place.
- Page 3 2. Next take the 32" adhesive Velcro strips and run it down the back of the roll cage facing towards the rear of the vehicle. Start at the bottom and work your way up the bar. You will see the double-sided Velcro tabs sewn along the back of the doors that will attach to this strip.
- Page 4 3. Next place two 3” adhesive strip on the center bar towards the bottom to match up with the two tabs as shown in the photo below. 4. Last piece of Velcro is the 3” strip on the end of the front strip as shown in the photo below.
- Page 5 5. Once all the Velcro is in place the last thing to do is install the screw snap studs. NOTE: The best way to install the snap studs is to put them in the sockets in the door first. Then push them into the plastic to make an mark. Then pull the screw stud out and screw it into the plastic where the mark was made.
-
Page 6: Rear Window
REAR WINDOW 7. Begin by placing the two 16" adhesive Velcro strip across the top of the roll cage. Make sure to place them on top of the bar on both sides of the rear brake light. Photo below shows how it should look. 8. - Page 7 9. The bottom of the Rear Window is held in place by 3 snaps. Photo below shows how this should go. TOP CAP Once you have the Lexan windshield installed on your Stampede use the straps with a loop sewn on one end. Wrap the looped end around the bar just under the bottom windshield clamp and then run the other end of the strap through the loop and pull it tight.
- Page 8 Next take the other two straps with a loop sewn on one end and wrap them around the roll cage in the rear just under the tab that the rear plastic panel is screwed to. It will help to raise the bed. See photo below Now place the top over the entire vehicle, the front of the top is identified by the sides not being as steeply curved, and begin by lacing the front straps through the ladder lock buckles sewn to the front corners of the top.
- Page 9 Cleaning and Storage Recommendations: Before removing the Over Armour Cab for storage, make sure it is very clean in order to prevent scratching of the window panels. Clean with a soft rag or sponge using a mild liquid detergent soap and warm water solution. Never rub the windows with a dry cloth or rag! Let the Cab dry thoroughly before attempting to roll for storage.
