Over Armour Offroad
Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
1. Be sure to read these instructions thoroughly before opening and installing the 2009-2013
Ranger Soft Door Rear Window Combo. The installation is best done when the
temperature is 70 degrees F. or warmer. The temperature affects the adhesive Velcro, if
conditions prevent installing in warmer weather it helps to store the adhesive Velcro at
room temperature prior to installation.
2. Carefully open the carton and remove the enclosure on a large flat surface that is clean
and free of dirt.
3. Check over the parts included in the carton with the parts list shown below:
Adhesive Velcro Hook Strips:
"
"
Snap Screw Studs
---------------------------------------------------------------------------
Adhesive Velcro Hook Strips:
"
"
"
The cab for your Ranger is made up of 3 different components that work together to enclose your
vehicle. Install the cab in the following order.
2515 Bypass Rd. Flemingsburg, KY 41041
606-845-7439
Instructions for Installation and Care of
2009-2010 Polaris Ranger
Soft Door Rear Window Combo
PO-10RANGER-DRW01
"
"
"
"
"
"
"
"
"
"
"
"
"
"
"
Soft Doors
18 each------------3"
2 each------------38"
14 each ( 2 extra )
Rear Window
8 each------------3"
1 each------------30"
1 each------------55"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PO-10RANGER-DRW01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Over Armour Offroad PO-10RANGER-DRW01

  • Page 1 Over Armour Offroad 2515 Bypass Rd. Flemingsburg, KY 41041 606-845-7439 Instructions for Installation and Care of 2009-2010 Polaris Ranger Soft Door Rear Window Combo PO-10RANGER-DRW01 Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
  • Page 2 Soft Doors 1. Begin by holding the door up to the frame and attach it using the double-sided Velcro strips sewn perpendicular to the edge of the door. At each of the double-sided strips take one of the 3" adhesive Velcro strips and adhere it to the inside of the frame. Then wrap the double-sided strip around it so that the adhesive strip holds it firmly in place.
  • Page 3 2. Next take the 38" adhesive Velcro strips and run it down the back of the roll cage facing towards the rear of the vehicle. Start at the bottom and work your way up the bar. You will see the double-sided Velcro tabs sewn along the back of the doors. See photos below.
  • Page 4 REAR WINDOW 4. Begin by placing the 30" adhesive Velcro strip centered across the top of the roll cage. Make sure to place them on top of the bar. 5. Next place the 55” strip across the bottom of the frame. It goes on the metal strip that faces the rear of the vehicle.
  • Page 5 Cleaning and Storage Recommendations: Before removing the Over Armour Cab for storage, make sure it is very clean in order to prevent scratching of the window panels. Clean with a soft rag or sponge using a mild liquid detergent soap and warm water solution. Never rub the windows with a dry cloth or rag! Let the Cab dry thoroughly before attempting to roll for storage.
