Over Armour Offroad CA-MAVERICKX3-4-RW01 Instructions For Installation And Care

Can-am maverick x3 (4door) rear window kit

Over Armour Offroad

Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab Material is Flammable.

1. Be sure to read these instructions thoroughly before opening and installing the Can Am

Maverick X3 (4 Door) Rear Window Kit. The installation is best done when the

temperature is 70 degrees F or warmer. The temperature affects the adhesive Velcro, if

conditions prevent installing in warmer weather, store the adhesive Velcro at room

temperature prior to installation.

2. Carefully open the carton and remove the enclosure on a large flat surface that is clean

and free of dirt.

3. Check the parts included in the carton with the parts list shown below:

Included Parts:

Soft Rear Window

2in Adhesive Backed Hook Velcro

If any parts are damaged or missing, please contact customer service at (606) 845-7439.

Note: Loosening, or even removing, a previously installed top will make installation much

easier.

2515 Bypass Rd. Flemingsburg, KY 41041

606-845-7439

Instructions for Installation and Care of

Can-Am Maverick X3 (4Door)

Rear Window Kit

CA-MAVERICKX3-4-RW01

1pcs

11pcs x 3in Length

1pc x 5in Length

1pc x 25in Length

Table of Contents

Need help?

Do you have a question about the CA-MAVERICKX3-4-RW01 and is the answer not in the manual?

Page 1 Over Armour Offroad 2515 Bypass Rd. Flemingsburg, KY 41041 606-845-7439 Instructions for Installation and Care of Can-Am Maverick X3 (4Door) Rear Window Kit CA-MAVERICKX3-4-RW01 Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab Material is Flammable.
Page 2 Rear Window Installation 1. Begin by holding the rear window up to the frame and attach it using the double-sided Velcro strips sewn onto the edge of the window. The edge of the window should be about 1/2in above the center line of the frame. Clean the area near each of the double-sided Velcro straps.
Page 3 2. Place two of the 3in adhesive hook Velcro strips on the frame in the top corners of the window. Use these to attach the corner tabs to the frame. The Image below shows the location of all the 3in Velcro strips. 3.
Page 4 Cleaning and Storage Recommendations: Before removing the Over Armour Cab for storage, make sure it is very clean in order to prevent scratching of the window panels. Clean with a soft rag or sponge using a mild liquid detergent soap and warm water solution. Never rub the windows with a dry cloth or rag! Let the Cab dry thoroughly before attempting to roll for storage.
