Over Armour Offroad KU-RTV900-WD03 Instructions For Installation And Care

Over Armour Offroad
NOTICE: Please check contents of package for any damage and make sure all parts fit
correctly and you are happy with the product before removing protective film. Once the
film is removed you cannot return the product for a full refund.
1. Be sure to read these instructions thoroughly before opening and installing the Kubota
RTV900 Lexan Windshield.
2. Check over the parts included in the cartons with the parts list shown below:
2" Loom Clamps
1" Stainless Steels Bolts
1 ¼" Stainless Steels Bolts
Stainless Steel Washers
Stainless Steel Lock Nuts
Plastic Thumb Nuts
Stainless Steel Nuts
52" Rubber Gasket
Lexan braces
Lexan Windshield
3. Start by pulling it out of the box and find a clean area to lay it down and install the
hardware. Next take the 52" piece of rubber gasket and starting at one end firmly place
along entire bottom edge of the Windshield. You will need to peel back the protective
film from the edge to install the gasket. If you leave the bulk of the protective film on
while installing you can keep from scratching the windshield.
4. Next take the two bent Lexan braces and install them on the windshield. You will notice
that one of the braces has a curved edge; this is the top brace and will go on the outside of
the windshield at the top of the windshield. The bend will be above the bolts when
installed. The bottom brace will go just below the hinge on the inside of the windshield.
As before the bend will be above the bolts, when installed the brace should look like a
shelf pointing towards the rear of the vehicle.
5. Now you are ready to place the windshield on the RTV and attach to the roll cage.
NOTE: THE BEND AT THE TOP OF THE WINDSHIELD SHOULD GO BELOW
THE TOP TUBE. The diagram on the next page shows the proper placement for the
hardware. Install the clamps as shown for the top two slots in the windshield only. Use
the 1" bolts for this application.
2515 Bypass Rd. Flemingsburg, KY 41041
606-845-7439
Instructions for Installation and Care of
Kubota RTV900
Folding Lexan Windshield
KU-RTV900-WD03
8 each
12 each
4 each
34 each
8 each
6 each
4 each
1 each
2 each
1 each
