Over Armour Offroad KU-X900-FC04 Instructions For Installation And Care

Over Armour Offroad
Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.
1. Be sure to read these instructions thoroughly before opening and installing the Kubota
RTV X900 Full Cab with Aero-Vent Poly Windshield. The installation is best done
when the temperature is 70 degrees F. or warmer. The temperature affects the adhesive
Velcro, if conditions prevent installing in warmer weather it helps to store the adhesive
Velcro at room temperature prior to installation.
2. Carefully open the carton and remove the enclosure on a large flat surface that is clean
and free of dirt.
3. Check over the parts included in the carton with the parts list shown below:
Adhesive Velcro Hook Strips:
"
"
"
"
"
"
Webbing straps with Grommet
Webbing Straps with Loops
Webbing Straps with Velcro
Cab Enclosure
4. Install the Polycarbonate Windshield first as per the instructions provided with it.
5. Begin by installing the Rear Window. Along the bottom of the rear window is a 53" long
Velcro strip. This will attach to the shelf under the expanded metal cage and along the
top of the seat back. Take the 53" adhesive Velcro strip and adhere it up under the shelf
with the Velcro facing down. Then attach the bottom of the rear window making sure to
center it and keep it straight. The photo on the next page shows how it should fit.
2515 Bypass Rd. Flemingsburg, KY 41041
606-845-7439
Instructions for Installation and Care of
Kubota RTV X900
Full Cab with Polycarbonate Windshield
KU-X900-FC04
" " "
" " "
" " "
" " "
" " "
" " "
35 each------------3"
6 each------------6"
4 each------------8"
2 each------------10"
2 each------------14"
2 each------------17"
1 each------------53"
2 each
2 each
2 each
4 panels
