Over Armour Offroad CA-MAVERICKX3-4-TC01 Instructions For Installation And Care

Can-am maverick x3 (4door) soft top cap

Over Armour Offroad

Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab Material is Flammable.

1. Be sure to read these instructions thoroughly before opening and installing the Can Am

Maverick X3 (4 Door) Soft Door Kit. The installation is best done when the temperature

is 70 degrees F or warmer. The temperature affects the adhesive Velcro, if conditions

prevent installing in warmer weather, store the adhesive Velcro at room temperature prior

to installation.

2. Carefully open the carton and remove the enclosure on a large flat surface that is clean

and free of dirt.

3. Check the parts included in the carton with the parts list shown below:

Included Parts:

Soft Top Cap

2in Adhesive Backed Hook Velcro

Webbing Straps with Velcro

If any parts are damaged or missing, please contact customer service at (606) 845-7439.

Note: Loosening or even removing a previously installed windshield will make installation

much easier.

Tools Needed for Installation:

No additional tools needed for installation.

2515 Bypass Rd. Flemingsburg, KY 41041

606-845-7439

Instructions for Installation and Care of

Can-Am Maverick X3 (4Door)

Soft Top Cap

CA-MAVERICKX3-4-TC01

1pc

4pcs x 3in Length

4pcs

Table of Contents

Need help?

Do you have a question about the CA-MAVERICKX3-4-TC01 and is the answer not in the manual?

Page 1 Over Armour Offroad 2515 Bypass Rd. Flemingsburg, KY 41041 606-845-7439 Instructions for Installation and Care of Can-Am Maverick X3 (4Door) Soft Top Cap CA-MAVERICKX3-4-TC01 Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab Material is Flammable.
Page 2 Soft Top Cap Installation 1. Begin by laying the top cap on to the roof of the unit. Make sure the end with the longer ears is oriented towards the front of the vehicle. 2. Place a piece of the adhesive backed Velcro around the roll cage on each of the 4 corners. This Velcro will be used to secure the nylon webbing strips that secure the top cap to the roll cage.
Page 3 5. Once all for corners are started, begin by tightening each corner slightly. Work your way around the vehicle tightening each corner but be sure to keep the edges of the top cap aligned with the roll cage. Keep working your way around the vehicle until the top cap is centered and secured tightly to the roll cage.
Page 4 Cleaning and Storage Recommendations: Before removing the Over Armour Cab for storage, make sure it is very clean in order to prevent scratching of the window panels. Clean with a soft rag or sponge using a mild liquid detergent soap and warm water solution. Never rub the windows with a dry cloth or rag! Let the Cab dry thoroughly before attempting to roll for storage.
