Over Armour Offroad KAW-610-MC01 Instructions For Installation And Care

610 mule mini cab enclosure

Over Armour Offroad

Instructions for Installation and Care of 610 Mule Mini Cab Enclosure

CAUTION: Do not smoke inside the cab or expose the enclosure to direct flames. Product is

Be sure to read these instructions thoroughly before opening and installing the enclosure.

Installation is best done when the temperature is 60

1. Carefully open the carton and unroll the enclosure on a large flat surface that is

clean and free of dirt or other material.

2. Check over the parts included in the carton with the parts list shown below:

Velcro hook strips

Enclosure

3. Loosely drape the enclosure over the roll cage. Note the correct position for the

10" latch strip on the underside of the front edge of the hood, in the center. Clean

the area with rubbing alcohol, let dry and apply one of the 10" Velcro hook strips.

Attach the enclosure to the strip under the hood. See fig.1.

2515 Bypass Rd. Flemingsburg, KY 41041

606-845-7439

KAW-610-MC01

FLAMMABLE.

6 each

3 each

1 each

2 each

1 each

Fig.1

F or warmer.

8" long

10" long

20" long

6" long

Table of Contents

Need help?

Do you have a question about the KAW-610-MC01 and is the answer not in the manual?

Page 1 Over Armour Offroad 2515 Bypass Rd. Flemingsburg, KY 41041 606-845-7439 Instructions for Installation and Care of 610 Mule Mini Cab Enclosure KAW-610-MC01 CAUTION: Do not smoke inside the cab or expose the enclosure to direct flames. Product is FLAMMABLE. Be sure to read these instructions thoroughly before opening and installing the enclosure.
Page 2 4. Working your way to the rear of the roll cage, carefully fit the enclosure into position. Pull the lower edge of the rear panel down between the rear of the roll cage and the front of the dump bed. Apply the 20” adhesive Velcro strip here(see fig.
Page 3 Put the rolled enclosure back into the carton for storage at a normal room temperature. It is best not to expose the enclosure to either extreme hot or cold temperatures when storing. 3. A special cleaner/conditioner is available from Mammoth Designs that will greatly increase the service life of the cab enclosure.
