Summary of Contents for Omron K35-2

  • Page 1 At the end of this document you will find links to products related to this catalog. You can go directly to our shop by clicking HERE. HERE...
  • Page 2 Digital Indicators K3HB Series Distinct by Design, Distinguished in Performance K3HB-H K3HB-S K3HB-X K3HB-V...
  • Page 3 Features Red-Green Display Allows Easy Recognition Short Body with Depth of Only 95 mm (from of Judgment Results Behind the Front Panel) • The measurement value display can be set to switch be- • A short body of only 95 mm (see note) contributes to the de- tween red and green in accordance with the status of com- velopment of slimmer and smaller control panels and instal- parative outputs.
  • Page 4 For applications that require safety, ensure that there is sufficient leeway in ratings and performances, install fail-safe measures, and take any other safety measures required by the application. In addition, contact your nearest OMRON representative and confirm specifications. K3HB-series Product Lineup ■...

  • Page 5: Process Indicator

    Process Indicator K3HB-X A Process Indicator Ideal for Discriminating and Displaying Measurements for Voltage/Current Signals • Easy recognition of judgement results using color display that can be switched between red and green. • Equipped with a position meter for monitoring operating status trends. •...

  • Page 6: Specifications

    Note: 1. DC power supply models require a control power supply capacity of approximately 1 A per Unit when power is turned ON. Particular attention is required when using two or more DC power supply models. The OMRON S8VS-series DC Power Supply Unit is recommend- 2.
  • Page 7 ■ Characteristics − 19,999 to 99,999 Display range Sampling period 20 ms (50 times/second) Comparative output response time DC input: 100 ms max.; AC input: 300 ms max. Linear output response time DC input: 150 ms max.; AC input: 420 ms max. 20 M Ω...
  • Page 8 ■ Input Range (Measurement Range and Accuracy) CAT II Input type Range Set value Measurement range Input Accuracy Allowable impedance instantaneous overload (30 s) 10 M Ω min. K3HB-XVD a Ud ±199.99 V ±0.1%rdg ± 1 ±400 V DC voltage digit max.
  • Page 9 Weighing Indicator K3HB-V An Ideal Indicator for OK/NG Judgements in Automated and Picking Machines, Measuring Factors such as Pressure, Load, Torque, and Weight Using Load Cell Signal Input. • Easy recognition of judgement results using color display that can be switched between red and green.
  • Page 10 Note: 1. DC power supply models require a control power supply capacity of approximately 1 A per Unit when power is turned ON. Particular attention is required when using two or more DC power supply models. The OMRON S8VS-series DC Power Supply Unit is recommend- 2.
  • Page 11 ■ Characteristics − 19,999 to 99,999 Display range Sampling period 20 ms (50 times/second) Comparative output response time 100 ms max. Linear output response time 150 ms max. 20 M Ω min. (at 500 VDC) Insulation resistance Dielectric strength 2,300 VAC for 1 min between external terminals and case Noise immunity 100 to 240 VAC models: ±...
  • Page 12 ■ Input Ranges (Measurement Range and Accuracy) Input type Range Set value Measurement range Input impedance Accuracy Allowable instantaneous overload (30 s) 1 M Ω min. K3HB-VLC a Ud 0.00 to 199.99 mV ±0.1%rdg ± 1 digit max. ±200 V Load Cell, mV b Ud 0.000 to 19.999 mV...

  • Page 13: Temperature Indicator

    Temperature Indicator K3HB-H New High-speed, High-precision Temperature Indicator • Easy recognition of judgement results using color display that can be switched between red and green. • Equipped with a position meter for monitoring operating status trends. • External event input allows use in various measurement and discrimina- tion applications.
  • Page 14 Note: 1. DC power supply models require a control power supply capacity of approximately 1 A per Unit when power is turned ON. Particular attention is required when using two or more DC power supply models. The OMRON S8VS-series DC Power Supply Unit is recommended.
  • Page 15 ■ Characteristics − 19,999 to 99,999 Display range Thermocouple input: (±0.3% PV or ±1 ° C, whichever is larger) ± 1 digit max. (See note.) Accuracy Platinum resistance thermometer input: (±0.2% PV or ±0.8 ° C, whichever is larger) ± 1 digit max. Sampling period 20 ms (50 times/second) Comparative output response time Platinum-resistance thermometer input range: 120 ms max.
  • Page 16 ■ Input Ranges Platinum-resistance Thermometer/Thermocouple Input type Platinum- Thermocouple resistance thermometer Name Pt100 (W/Re 5-26) Connected terminals Tem- 2300.0 2300 pera- 1700.0 1700.0 1800.0 ture 1800 1300.0 1300.0 range 1300 ( ° C) 850.0 850.0 850.0 500.0 600.0 400.0 400.0 400.0 150.00 100.0...
  • Page 17 Linear Sensor Indicator K3HB-S A Linear Sensor Indicator Capable of High-speed Response at 2,000 Times per Second • Effective for high-speed measurement and discrimination with a sam- pling period of 0.5 ms and output response time of 1 ms max. •...
  • Page 18 Note: 1. DC power supply models require a control power supply capacity of approximately 1 A per Unit when power is turned ON. Particular attention is required when using two or more DC power supply models. The OMRON S8VS-series DC Power Supply Unit is recommend- 2.
  • Page 19 ■ Characteristics − 19,999 to 99,999 Display range Sampling period One input: 0.5 ms; Two inputs: 1.0 ms Comparative out- One input OFF to ON: 1 ms max., ON to OFF: 1.5 ms max. put response Two inputs OFF to ON: 2 ms max., ON to OFF: 2.5 ms max. times (transistor outputs) Linear output re-...
  • Page 20 Input type DC current input Input type DC voltage input 0-20 4-20 Connected terminals Connected terminals in-ta in-ta Input A Input A in-tb in-tb Input B Input B DC current 22.000 22.000 DC voltage 24.000 range (mA) range (V) 11.000 20.000 16.000 10.000...

  • Page 21: Common Specifications

    Common Specifications ■ Event Input Ratings Input type S-TMR, HOLD, RESET, ZERO, BANK1, BANK2, TIMING BANK4 ON: 1 k Ω max., OFF: 100 k Ω min. Contact No-contact ON residual voltage: 2 V max. ON residual voltage: 3 V max. OFF leakage current: 0.1 mA max.

  • Page 22: Devicenet Communications

    DeviceNet Communications Communications protocol Conforms to DeviceNet Supported communi- Remote I/O communications Master-Slave connection (polling, bit-strobe, COS, cyclic) cations Conforms to DeviceNet communications standards. I/O allocations Allocate any I/O data using the Configurator. Allocate any data, such as DeviceNet-specific parameters and variable area for Digital Indicators.
  • Page 23 ■ Power Supply Derating Curve for Sensor (Reference Value) With 12 V With 10 V Max. current (mA) Max. current (mA) −20 −10 −20 −10 Ambient temperature (°C) Ambient temperature (°C) Note: 1. The above values are for standard mounting. The derating curve differs depending on the mounting conditions. 2.

  • Page 24: Continuous Data Output

    Refer to the following User's Manual for application precautions and other information required when using the Digital Indicator: K3HB-S/-X/-V/-H Digital Indicator User's Manual (Cat. No. N128) The manual can be downloaded from the following site in PDF format: OMRON Industrial Web http://www.fa.omron.co.jp K3HB-X/-V/-H/-S...

  • Page 25: Terminal Arrangement

    BCD (NPN Open Collector): BCD Applicable Connector (Sold separately) 0-20/ 0-20/ HDR-E50MAG1 4-20 mA 4-20 mA − (HONDA TSUSHIN KOGYO CO., LTD.) Special Cable (Sold separately) K32-BCD (OMRON) − (HDR-E50MAG1 with 0.3-m cable) <K33- <K33- <K33- <K33- L2B> L1B> L2A>...
  • Page 26 HOLD RESET: D4 ZERO: D5 TIMING 560 Ω 4.7 kΩ RESET ZERO 750 Ω 3.9 kΩ Models with Connectors <K35-2><K35-4> 1: TIMING 2: S-TMR 3: HOLD 4: RESET 5: ZERO 6: COM 7: BANK4 8: BANK2 9: BANK1 10: COM •...
  • Page 27 ■ Main Functions Measurement Input Calculation • Two input circuits are provided. The input ranges for these circuits can be set independently. For example, one can be set to 4 to 20 mA and the other can be set to 1 to 5 V. •...
  • Page 28 ■ Input Compensation/Display Display Value Selection Forced-zero X V H S X V S The current display value can be selected from the present value, the Forces the present value to 0. (Convenient for setting reference val- maximum value, and the minimum value. ues or deducting tares for weight measurement.) Step Value X V H S...
  • Page 29 ■ Output Comparative Output Pattern Hysteresis X V H S X V H S Prevents comparative output chattering when the measurement The output pattern for comparative outputs can be selected. In addi- value fluctuates slightly near the set value. tion to high/low comparison with set values, output based on level changes is also possible.
  • Page 30 The waterproof packing ensures a level of waterproofing that con- forms to NEMA 4X. Depending on the operating environment, deteri- oration, contraction, or hardening may occur and replacement may be necessary. In this case, consult your OMRON representative. K3HB-X/-V/-H/-S Digital Indicators...

  • Page 31: Precautions For Safe Use

    ■ Precautions Precautions for Safe Use !WARNING 1. Do not use the product in the following locations. Do not touch the terminals while power is being supplied. • Locations subject to direct radiant heat from heating equipment Doing so may possibly result in electric shock. Make sure •...
  • Page 32 21.Do not connect or remove connectors while the DeviceNet power is being supplied. Doing so will cause product failure or malfunc- tion. 22.Use cables with a heat resistance of 70ºC min. ■ Noise Countermeasures 1. Do not install the product near devices generating strong high-fre- quency waves or surges, such as high-frequency welding and sewing machines.

  • Page 33: Warranty And Limitations Of Liability

    Warranty and Limitations of Liability ■ WARRANTY OMRON's exclusive warranty is that the products are free from defects in materials and workmanship for a period of one year (or other period if specified) from date of sale by OMRON. OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, REGARDING NON-INFRINGEMENT, MERCHANTABILITY, OR FITNESS FOR PARTICULAR PURPOSE OF THE PRODUCTS.
  • Page 34 Alim 180122 K32-BCD Buy on EAN Indicators for Panel, Cable K3HB BCD - Dsub 37Pin 118252 K35-2 Buy on EAN Panel Indicators, Tarj K3HB Event 8-NPN input 118253 K35-4 Buy on EAN Panel Indicators, CARD PROCESSOR / INTELLIGENT DISPLAY...
