Print Control Commands; Power Supply; Operation Environment; Outline Dimension - SPRT SP-POS892 User Manual

Standard USB interface
● Cash Drawer Control
DC24V, 1A, 6-pin RJ-11 socket.

1.5 Print Control Commands

● Character print commands: support double-width, double height print of ANK
characters, user-defined characters and Chinese characters, the character line
spacing is adjustable.
● Graphics print commands: support the print of bit-map graphics and download
bit-map graphics with different density
● GS bar code print commands:
support UPC-A， UPC-E， EAN-13， EAN-8， CODE39， ITF25， CODEBAR， CODE93，
CODE128,PDF417,QR code，DATA Matrix code print.

1.6 Power Supply

● DC24V±10％, 1.5A, A-1009-3P power socket

1.7 Operation Environment

● Operation temperature: 0～50℃; Relative humidity: 10～80％
● Storage temperature: -20～60℃; Relative humidity: 10～90℃

1.8 Outline Dimension

● 179(L)mm×152(W) mm×118 (H)mm

1.9 Model classification

Model Interface
3
Print speed (Max)
