Your local VIP Vision™ professional:
Available in 2MP, 4MP, 12MP WDR and Ultra WDR variants
Thank you for purchasing a FBIR Series CCTV Surveillance Camera.
This Quick Install Guide covers basic setup, installation and use of your surveillance system.
For the full user manual, instructional videos, tips on using your surveillance system &
warranty information, please visit: www.vip-vision.com
Applicable Models
VSIP4MPFBIRM
VSIP2MPFBIRMT
VSIP2MPFBIRL
VSIP12MPFBIRMV2
Camera Quick Install Guide
FBIR Series
4.0 MP WDR Infrared Motorised Bullet
2.0 MP Number Plate Enhancement Bullet
2.0 MP Ultra WDR Infrared Motorised Bullet
12.0 MP Infrared Motorised Bullet
Version 290517
www.activeonline.com.au 1300 816 742
Advertisement
Table of Contents
Related Manuals for Vip-Vision FBIR Series
Summary of Contents for Vip-Vision FBIR Series
- Page 1 FBIR Series Available in 2MP, 4MP, 12MP WDR and Ultra WDR variants Thank you for purchasing a FBIR Series CCTV Surveillance Camera. This Quick Install Guide covers basic setup, installation and use of your surveillance system. For the full user manual, instructional videos, tips on using your surveillance system &...
-
Page 2: Important Safeguards And Warnings
FBIR Series | Surveillance Cameras Important Safeguards and Warnings Electrical safety • All installation and operation here should conform to your local electrical safety codes. • Check if the power supply is correct before operating the device. • The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated DC 12V or AC 24V in the IEC60950-1. - Page 3 FBIR Series | Surveillance Cameras Operation and Daily Maintenance • Do not touch the heat dissipation component of the device directly in order to avoid scald. • Do not dismantle the device; there is no component which can be fixed by users themselves in the machine. It may cause water leakage or bad image for the device due to unprofessional dismantling.
-
Page 4: Included Components
FBIR Series | Surveillance Cameras Pre-install Information Included Components FBIR Series IP Camera Quick Start Guide Installation Accessories Bag: • Position installation map • Expansion bolts • Locking screws • Screwdriver Dimensions Connection ports Port Name Function AUDIO OUT Audio output port (RCA connector) -
Page 5: Installing The Camera
1. Installing the camera Here will we walk through the installation process for your ‘‘FBIR Series’’ camera. We will show you how to set-up your equipment, how to adjust it, all of its components and how to get it up and running. Be sure to check the pre-install to have an understanding of the included components, dimensions, and connection ports. -
Page 6: Installing The Microsd Card
FBIR Series | Surveillance Cameras 1.2 Accessing the microSD card slot (optional) 1.2.1 Installing the microSD card 1.2.2 Advantages of the microSD The microSD card is a very useful tool for anyone 1. Locate the lower cover on the bottom of the camera. - Page 7 FBIR Series | Surveillance Cameras 1.4 Waterproofing Note: Waterproofing may differ - this is only applicable to the ‘FBIR Series’ cameras. Note: Waterproofing is applied on the Network Port connector. 1. Install the ruber ring into the network port, keep the smaller hole of the rubber ring outward and install the fixing rubber ring onto the main body of the waterproof cable.
-
Page 8: Alarm Setup
FBIR Series | Surveillance Cameras 1.5 Alarm Setup 1. Connect alarm input device to the alarm input of I/O cable. 2. Connect alarm output device to the alarm output of I/O cable. 3. Open the WEB, set alarm input and output. Alarm input on WEB corresponds to I/O cable on device. When there is an alarm, the input device will generate a signal of high and low level. - Page 9 Please visit our website or contact your local service engineer for more information. Your local VIP Vision™ professional: www.activeonline.com.au 1300 816 742 For the full user manual, instructional videos, tips for using your surveillance system and warranty information, please visit: www.vip-vision.com...
