VDIRME Series
Thank you for purchasing a VDIRME Series CCTV Surveillance Camera.
This Quick Install Guide covers basic setup, installation and use of your surveillance system.
For the full user manual, instructional videos, tips on using your surveillance system &
warranty information, please visit: www.vip-vision.com
Applicable Models
VSIP2MPVDIRME
VSIP4MPVDIRME
VSIP8MPVDIRM
Camera Quick Install Guide
Available in Low Light 2.0MP, 4.0MP and 8.0MP variants
2.0MP Professional Ultra Low Light Motorised Dome
4.0MP Professional Motorised Dome
8.0MP Professional Motorised Dome
Version 290517
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vip-Vision VDIRME Series
Summary of Contents for Vip-Vision VDIRME Series
- Page 1 VDIRME Series Available in Low Light 2.0MP, 4.0MP and 8.0MP variants Thank you for purchasing a VDIRME Series CCTV Surveillance Camera. This Quick Install Guide covers basic setup, installation and use of your surveillance system. For the full user manual, instructional videos, tips on using your surveillance system &...
- Page 2 VDIRME Series | Surveillance Cameras Important Safeguards and Warnings Electrical safety • All installation and operation here should conform to your local electrical safety codes. • Check if the power supply is correct before operating the device. • The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated DC 12V or AC 24V in the IEC60950-1.
- Page 3 VDIRME Series | Surveillance Cameras Operation and Daily Maintenance • Do not touch the heat dissipation component of the device directly in order to avoid scald. • Do not dismantle the device; there is no component which can be fixed by users themselves in the machine. It may cause water leakage or bad image for the device due to unprofessional dismantling.
- Page 4 VDIRME Series | Surveillance Cameras Pre-install Information Included Components VDIRM Series IP Camera Quick Start Guide Installation Accessories Bag: • Position installation map • Expansion bolts • Installation screws • Screwdriver Dimensions Device framework Component Name Photosensor IR light Lens...
- Page 5 1. Installing the camera Here will we walk through the installation process for your ‘‘VDIRME Series’’ camera. We will show you how to set- up your equipment, how to adjust it, all of its components and how to get it up and running. Be sure to check the pre-install to have an understanding of the included components, dimensions, and connection ports.
- Page 6 VDIRME Series | Surveillance Cameras 1.2 Accessing the microSD card slot (optional) Fig 1.2 Fig 1.2.1 1.2.1 Installing the microSD card 1. Use the screwdriver in accessories bag to loosen the four screws on the dome pedestal, then take down the compression cover and take out the dome body.
- Page 7 VDIRME Series | Surveillance Cameras 1.3 Cable management Bottom Wiring: Side Wiring: Lead the cable out through ceiling/wall, which can Lead the cable out through side exit and add metal protect and hide the cable effectively. conduit, to prevent cable from being damaged.
- Page 8 Please visit our website or contact your local service engineer for more information. www.activeonline.com.au 1300 816 742 Your local VIP Vision™ IP solutions professional: For the full user manual, instructional videos, tips for using your surveillance system and warranty information, please visit: www.vip-vision.com...
