Thank you for purchasing a FEIR Series CCTV Surveillance Camera.
This Quick Install Guide covers basic setup, installation and use of your surveillance system.
For the full user manual, instructional videos, tips on using your surveillance system &
warranty information, please visit: www.vip-vision.com
Applicable Models
VSIP6MPFEIRV2
VSIP12MPFEIRV2
Camera Quick Install Guide
FEIR Series
Available in 6MP and 12MP variants
6.0 MP WDR Infrared 360° Fisheye Dome (special order only)
12.0 MP WDR Infrared 360° Fisheye Dome
Version 080917
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vip-Vision VSIP12MPFEIRV2
Summary of Contents for Vip-Vision VSIP12MPFEIRV2
- Page 1 Thank you for purchasing a FEIR Series CCTV Surveillance Camera. This Quick Install Guide covers basic setup, installation and use of your surveillance system. For the full user manual, instructional videos, tips on using your surveillance system & warranty information, please visit: www.vip-vision.com Applicable Models VSIP6MPFEIRV2 6.0 MP WDR Infrared 360°...
-
Page 2: Important Safeguards And Warnings
FBIR Series | Surveillance Cameras Important Safeguards and Warnings Electrical safety • All installation and operation here should conform to your local electrical safety codes. • Check if the power supply is correct before operating the device. • The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited power source is rated DC 12V or AC 24V in the IEC60950-1. - Page 3 Note: Refer to the disk for more details, check and download corresponding user’s manual and tool. Before installation, please open the package and check all the components are included. Contact your local retailer ASAP if something is broken in your package www.vip-vision.com...
- Page 4 FBIR Series | Surveillance Cameras Pre-install Information Included Components FBIR Series IP Camera Quick Start Guide Installation Accessories Bag: • Position installation map • Expansion bolts • Locking screws • Screwdriver Dimensions Connection ports Port Name Function AUDIO OUT Audio output port (RCA connector) AUDIO IN Audio input port (RCA connector) Network port (Ethernet connector)
-
Page 5: Installing The Camera
4. Install microSD card (optional) (1.2). 5. Adjust monitoring direction of the device (1.3). 6. Apply waterproofing to network cable (1.4) and then plug in all necessary ports (shown in pre-install). 7. Setup your alarm system (1.5). 8. Your setup is complete! www.vip-vision.com... -
Page 6: Adjusting The Camera Angle
FBIR Series | Surveillance Cameras 1.2 Accessing the microSD card slot (optional) 1.2.1 Installing the microSD card 1.2.2 Advantages of the microSD The microSD card is a very useful tool for anyone 1. Locate the lower cover on the bottom of the camera. who wishes to have another way to back up storage, 2. - Page 7 3. Put the main body of the waterproof connector on the network port and rotate it clockwise to lock the network port and waterproof connector firmly. 4. Put the waterproof locking cover on the main body of the waterproof connector and rotate it clockwise to lock the waterproof connector and waterproof locking cover firmly. www.vip-vision.com...
-
Page 8: Alarm Setup
FBIR Series | Surveillance Cameras 1.5 Alarm Setup 1. Connect alarm input device to the alarm input of I/O cable. 2. Connect alarm output device to the alarm output of I/O cable. 3. Open the WEB, set alarm input and output. Alarm input on WEB corresponds to I/O cable on device. When there is an alarm, the input device will generate a signal of high and low level. - Page 9 Please visit our website or contact your local service engineer for more information. Your local VIP Vision™ professional: www.activeonline.com.au 1300 816 742 For the full user manual, instructional videos, tips for using your surveillance system and warranty information, please visit: www.vip-vision.com...
