WisyCom MPR30-IFB User Manual page 8

ON Led Indicators (Firmware rel. v1.5)
COLOR WHEN
During the power up phase
Red
After the power up phase
After the power up phase
Fixed Green
During a battery charge
After the power up phase
Slow Blinking
Green
During a battery charge
Fast Blinking
After the power up phase
Green
Green/Red
During a scan operation
blinking
Blue During a battery charge
"Pink" In the boot mode
RF Led Indicators (Firmware rel. v1.5)
COLOR RF level
RF>Squelch
Red RF<Squelch
RF<Squelch
RF>Squelch
Green RF<Squelch
RF>Squelch
"Orange"
* to put the MPR30-IFB in boot mode: power on the device push and keep both UP and DOWN buttons for few
seconds (until the led indicators light up, then release the buttons)
7
MEANING
The receiver is not ready to use
The PLL is not locked on the select frequency, wait
for lock ( about 1second or less). If after few
seconds the ON led remains red, contact Wisycom
The receiver is locked on the select frequency, the
batteries charge is good (
Charge complete
The receiver is locked on the select frequency, the
batteries charge is low (
The batteries are charging (≥90% of charge
reached)
The receiver is locked on the select frequency, the
batteries charge is very low (
The device is doing a scan of the frequencies
The batteries are charging (<90% of complete
charge)
The device is in the boot mode
TONE SQUELCH (19KHz)
Enable but not detected
Enable but not detected
Disable
Enable and detected
Enable and detected
Disable
The device is in the boot mode
MPR30-IFB User Manual
>25% lifetime)
<25% lifetime)
<12% lifetime)
AUDIO Why is audio disable?
Disable Tone squelch not detected
Disable Tone squelch not detected
Disable RF<Squelch
Enable
Disable RF<Squelch
Enable
Rev. 03
