WisyCom MPR30-IFB User Manual page 5

B
ATTERIES
MPR30-IFB works with standard camera battery:
- 2xIEC-LR6 1.5 size-AA alkaline or NiMh rechargeable
- KLIC 8000 (lithium-ion, rechargeable)
- Ricoh DB-50 (lithium-ion, rechargeable)
- DR9708 Duracell (lithium-ion, rechargeable)
Battery status can be checked on OLED display or looking the status of
Lithium-ion battery can be charged through
A. dedicated charger
B. integrated micro-usb-B connector
For B item, the charging status can be checked looking the status of
The receiver can be used also during the batteries charging with lithium
rechargeable batteries inside.
Don't use the receiver without batteries . The receiver powered thru micro-USB without
batteries doesn't work correctly.
DO NOT operate the device with some new and some old batteries. Always replace
ALL BATTERIES.
Remember to remove the batteries when the device is not in use.
4
MPR30-IFB User Manual
LED indicator ON.
LED indicator
Rev. 03
ON.
