- Page 1 Assembly and Operation Guide AG25T CANTILEVER AG25T 11.5’ octagon AG25TSQ 10’ square...
- Page 2 Thank you for purchasing Treasure Garden’s AG25T Cantilever. Please remove all contents from the package, inspect and review checklist. Some parts may be included in the styrofoam packaging. Do not discard any packaging or box until assembly is complete. CHECKLIST A - (1) 360°...
- Page 3 NOTE: REFER TO SEPARATE BASE OR MOUNT KIT MANUAL FOR BASE ASSEMBLY PRIOR TO PROCEEDING. IMPORTANT: For free standing base applications, it is imperative to install the appropriate base for your size cantilever. The minimum base weight recommended for the AG25T is 200 lbs. STEP UMBRELLA ASSEMBLY Two-persons recommended for team lift and to complete assembly.
- Page 4 STEP OPENING UMBRELLA Position yourself behind umbrella. In the closed position, turn adjustment knob counter clockwise (Fig. 3) and slide the adjustment knob upward (Fig. 4). Turn adjustment knob clockwise to tighten and secure in place. (Fig. 3) (Fig. 4) Insert crank handle into “Open/Close”...
- Page 5 STEP TILTING UMBRELLA To Tilt Canopy Vertically: IMPORTANT: PRIOR TO USING VERTICAL AND HORIZONTAL TILT FEATURE. To avoid personal injury or damage to the umbrella, make sure the area behind you is clear and free from any furniture or structure. Position yourself behind umbrella.
- Page 6 STEP ROTATING UMBRELLA Place your foot on the foot pedal of the rotating hub and step-on the pedal to release rotating lock (Fig. 10). Place hands on the main frame and rotate the umbrella frame in either direction, in 90° increments. To lock position, step off the foot pedal to engage rotating lock.
-
Page 7: Care And Maintenance
STEP CLOSING UMBRELLA Position yourself behind umbrella. Insert crank handle into “Open/Close” socket in crank mechanism (Fig. 13). Turn crank handle counter clockwise until the canopy is closed (Fig. 14). Turn adjustment knob counter clockwise and slide downward until umbrella is in closed position. -
Page 8: Safety Precautions
Tampering with or altering the product will Additionally, acts of nature (including but void warranty. not limited to wind, hurricanes, tornadoes, and storms) are not covered by this In the event that warranted factory service warranty. www.treasuregarden.com ©2021 Treasure Garden, Inc. - All Rights Reserved. v.05.18.21...
